Unshield Twisted Pair Cable Solid UTP Cat5e
Hangzhou Risun Cable Co., Ltd.- Application：Local Communication Cable, LAN Cable
- Conductor Material：Copper
- Cover Material：PVC,PE,LSZH
- Type：Cat5e
- Material Shape：Round Wire
- Conductor Type：Solid
Base Info
- Model NO.：Cat5e
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS, ETL
- Brand：Risun or OEM
- Transport Package：Wooden Reel, CTN
- Specification：CE, ROHS, ISO9001 ETL
- Trademark：Risun or OEM
- Origin：Hangzhou, China(Mainland)
- HS Code：8544491100
- Production Capacity：20000 Boxes , Month
Description
Type&SpecificationAs per ANSI/TIA/EIA, ISO/IEC standard Type AWG Conductor Insulation Rated Temperature PTT298 24 Bare copper HDPE 75ºC Characteristics ITEM Unite Value Characteristic impedance Ω 100±15 Conductor resistance, maximum, Ω/km (20ºC) 98.7 Mutual pairs capacitance nf/km 62 Dielectric strength (DC test voltage for 1 min, ) DC (V) 1000 Insulation resistance, minimum, M Ω /km 5000 Transmission Characteristics Frequency Attenuation NEXT (MHz) (db/100m) (db) 1 2.1 62 4 4.3 53 10 6.6 47 16 8.2 44 20 9.2 42.5 31.25 11.8 39.5 62.5 17.1 35
