AAAC Conductor Aluminio Desnudo Alton AAAC Aster 570 Overhead Conductor
Henan Hongda Cable Co., Ltd.- Application：Construction, Overhead, Industrial
- Voltage：High Voltage Cable
- Current：DC Cable
- Insulation Material：No
- Sheath Material：Bare
- Material Shape：Round Wire
Base Info
- Model NO.：Overhead Conductor
- Wire Core Material：Aluminium Alloy
- Certification：ISO, CCC, SGS
- Model：Almelec Conductor
- Brand：Hongda
- Standard：ASTM B-398
- Transport Package：1000m Per Export Drum
- Specification：Alton, Akron, Butte, Canton
- Trademark：Hongda
- Origin：China
- HS Code：7614900000
- Production Capacity：1500km,Month
Description
gauges and wiring of
acsr cables of the same
diameter as those of alloyNumber of wire per
diameter of each wire diameter total Approx. Weight
total breaking load Direct current
resistance at 20 ºC KCMIL mm2 AWG or MCM Al/Acero mm mm kg/km kg ohms/km Akron 30.58 15.5 6 6/1 7x1.68 5.04 42.44 503 2.1615 Alton 48.69 24.67 4 6/1 7x2.12 6.36 67.56 801 1.3577 Ames 77.47 39.25 2 6/1 7x2.67 8.02 107.5 1270 0.8534 Azusa 123.3 62.48 1/0 6/1 7x3.37 10.11 171 2023 0.5364 Anaheim 155.4 78.74 2/0 6/1 7x3.78 11.35 215.6 2452 0.4257 Amherst 195.7 99.16 3/0 6/1 7x4.25 12.74 271.5 3083 0.3379 Alliance 246.9 125 4/0 6/1 7x4.77 14.31 342.6 3884 0.2658 Butte 312.8 158 266.8 26/7 19x3.26 16.3 434.9 4978 0.2113 Canton 394.5 200 366.4 26/7 19x3.66 18.3 547.4 6013 0.1675 Cairo 465.4 236 397.5 26/7 19x3.98 19.88 645.7 7098 0.1421 Darien 559.5 283 477 26/7 19x4.36 21.79 776.3 8525 0.1181 Elgin 652.4 331 556.5 26/7 19x4.71 23.53 905.2 9943 0.10135 Flint 740.8 375 636 26/7 37x3.59 25.16 1028 9943 0.0892 Greeley 927.2 470 795 26/7 37x4.02 28.15 1287 11014 0.0713 1077.4 545.9 954 54/7 61x3.38 30.42 1495 15909 0.0614 1165.1 590.3 1033.5 54/7 61x3.51 31.59 1617 17234 0.0567 1259.6 638.2 1113 54/7 61x3.65 32.85 1748 18560 0.05249 1348.8 683.4 1192.5 54/7 61x3.90 35.1 1872 21212 0.04594
acsr cables of the same
diameter as those of alloy
diameter of each wire
total
resistance at 20 ºC
Conductor's workability
All Aluminum Alloy Conductor consist of 6201-T81 Aluminum Alloy wires, which largely looks like the 1350 grade Aluminum conductor. It offers good electrical conductivity. DC resistance at 20 degrees Celsius for the 6201-T81 series has a greater abrasive resistance than 1350-H19 Aluminum conductor series. The conductor is also resistant to moisture and weather. It is lightweight and flexible hence requires less effort to move around during installation.
