• Model NO.：15kv XLPE
• Material Shape：Round Wire
• Range of Application：Construction or Building
• Certification：ISO9001, CE, CCC
• Trademark：vicj
• Origin：China

Basic Info.

Model NO. 15kv XLPE Material Shape Round Wire Range of Application Construction or Building Certification ISO9001, CE, CCC Trademark vicj Origin China

Product Description

Copper Conductor MV Steel Wire Armoured Power Cable

XLPE insulated power cable has a number of advantages over paper insulated and PVC insulated cable. XLPE power cable has high electric strength, mechanical strength, high-ageing resisting, environmental stress resisting, anti-chemical corrosion, and it is simple construction, using convenient and higher operation of long term temperature. It can be laid with no drop restriction.


The flame-retardant and non-flame retardant XLPE cable can be manufactured with three technologies (peroxide, silane and irradiation cross-linking). The flame-retardant cable covers all kinds of low-smoke low-halogen low-smoke halogen free and non-smoke non-halogenated and three classes of A, B, C.

1. Conductors: Copper or aluminum.

2. Both armored and non-armored type power cables are available.

3. Voltage rating: 6/10kV 8.7/15kV 26/35kV.

4. PVC or PE sheathed.

1  core	1*10;   1*16;   1*25;   1*35;   1*50;   1*70;   1*95;   1*120;   1*150;   1*185;   1*240;   1*300;   1*400
2  core	2*1.5;   2*2.5;   2*4;   2*6;   2*10;   2*16;   2*25;   2*35;   2*50;   2*70;   2*95;   2*120;   2*150;   2*185;   2*240;   2*300
3core	3*1.5;   3*2.5;   3*4;   3*6;   3*10;   3*16;   3*25;   3*35;   3*50;   3*70;   3*95;   3*120;   3*150;   3*185;   3*240;   3*300
4  core	4*4;   4*6;   4*10;   4*16;   4*25;   4*35;   4*50;   4*70;   4*95;   4*120;   4*150;   4*185;   4*240
5  core	5*1.5;   5*2.5;   5*4;   5*6;   5*10;   5*16;   5*25;   5*35;   5*50;   5*70;   5*95;   5*120;   5*150;   5*185;   5*240;
3+1 core	3*4+1*2.5;   3*6+1*4;   3*10+1*6;   3*16+1*10;   3*25+1*16;   3*35+1*16;   3*50+1*25;   3*70+1*35.
4+1 core	4*2.5+1*1.5;   4*4+1*2.5;   4*6+1*4;   3*10+1*6;   4*16+1*10;   4*25+1*16;   4*35+1*16;   4*50+1*25;   4*70+1*35;   4*95+1*50;   4*120+1*70;   4*150+1*70;   4*185+1*95;   4*240+1*120;   4*300+1*150.
