UL1007 Copper Conductor PVC Insulation
B&T (Zhangzhou) Cable Co., Ltd.- Application：Local Communication Cable, Coaxial Cable, Long Distance Symmetric Cable
- Conductor Material：Copper
- Cover Material：PVC
- Type：Hook-up Wire
- Material Shape：Round Wire
- Conductor Type：Stranded
Base Info
- Model NO.：UL1007
- Wire Core Material：Tinned Wire
- Certification：CE, ISO, RoHS, CCC, UL
- Model：UL1007
- Brand：Bort
- Color：White Blue Red Black Yellow
- Weight：About 1kg,1000FT
- Rated Voltage：300V
- UL Flame Test：UL Vm-1& FT1
- Current：DC,AC
- Production Process：Welding
- Species：Terminal
- Character：Environmental Protection
- User：Socket Terminals
- Factory Management：ISO9001:2008
- Transport Package：Coil
- Specification：Customize
- Trademark：BORT
- Origin：China
- HS Code：8544492900
- Production Capacity：500000km,Per Year
Description
AWGNO.of Cond Insulation Thick. Outside Thick. Packing mm mm mm m/r Ω/mm 30 7/0.1 0.41 1.10 610 354.33 28 7/0.127 0.41 1.20 610 223.75 26 7/0.16 0.41 1.30 610 139.76 24 11/0.16 0.41 1.40 610 88.36 22 17/0.16 0.41 1.60 610 60.16 20 21/0.178 0.41 1.80 610 38.58 18 34/0.178 0.41 2.10 610 22.98 16 26/0.254 0.41 2.40 610 15.06 28 1/0.320 0.41 1.15 610 227.39 26 1/0.404 0.41 1.25 610 142.79 24 1/0.511 0.41 1.35 610 89.39 22 1/0.643 0.41 1.50 610 54.30 20 1/0.813 0.41 1.65 610 33.90 18 1/1.024 0.41 1.85 610 21.40
