B9d Cable Torsion Resistant Loop Screened LSZH1kv Turbine Cable for Wind Turbines

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：Hf-EVA
  • Insulation Material：Epr
  • Material Shape：Round Wire

Base Info

  • Model NO.：B9D Cable
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, CCC, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemB9D Cable ConductorStranded bare copperInsulationEPR (Ethylene Propylene Rubber)ScreenTWCB (Tinned wire copper braid)Outer sheathHF-EVA (Halogen Free Ethylene-Vinyl Acetate)Rated voltage Uo/U: 0.6/1kVCore numberMulticores (As client's requirement)Testing voltageFixed: -40 ºC ~ +90 ºC
Flexed: -35 ºC ~ +90 ºCMin. bending radiusFixed: 4x Overall Diameter
Flexing: 6x Overall DiameterTorsion Resistance± 100°/mApplicationTorsion resistant loop screened power cables are designed for special application conditions in wind turbines where under medium mechanical stress and for operation outdoors or under permanent influence of seawater. Oil, UV, Ozone resistant.
