• Model NO.：SC,UPC-LC,UPC
• Core：Single Core
• Certification：RoHS, ISO9001
• Brand：OEM
• Sheath Material：PVC
• Insertion Loss：Il<0.25dB
• Return Loss：Upc > 50dB ; APC> 60dB
• Transport Package：Carton
• Specification：0.9,2.0,3.0mm
• Trademark：SMD
• Origin：Shenzhen China
• HS Code：8544700000
• Production Capacity：100000,Month

Fiber Optic Patchcord

Features		Applications
> Compliant with Telcordia GR-326-Core, TIA/EIA and IEC > Customer length > Various connector type available > Environmental stable		> Telecommunication network > CATV system > Local Area Network > Active/Passive device > FTTH and FTTx

SpecificationOptical PerformanceSingle ModeMulti ModeInsertion Loss≤0.20dB≤0.30dBReturn Loss≥45dB(PC)≥35dB≥50dB(UPC)≥60dB(APC)Repeatability≤0.10dBDurability≤0.2dB typical change,1000 matingsOperating Temperature- 20 ~ +75ºCStorage Temperature- 40 ~ +85ºCEndface GeometryParameter2.5μm ferrule
 1.25μm ferruleUPCAPCUPCAPCRadius of Curvature10~25mm5~12mm7~25mm5~12mmApex Offset0~50μm0~50μm0~50μm0~50μmFiber Height-100~50nm-100~100nm-100~50nm-100~100nmAngle--7.7-8.3degree--7.7-8.3degree3D - Geometry
Assembly
Type
FiberCore
Connector
Type
Fiber Type
Cable
diameter
Cable
Jacket Type
Cable Color
Length
PC:PATCHCORD
PT:PIGTAIL
Simplex:1
Duplex:2
.
.
.
SCP:SC/PC
SCA:SC/APC
FCP:FC/PC
FCA:FC/APC
SM:9/125
M5:50/125
M6:62.5/125
OM:OM3 50/125
09:0.9mm
16:1.6mm
20:2.0mm
30:3.0mm
P:PVC
L:LSZH
YE:YELLOW
OR:ORANGE
AQ=AQUA
11-99m
