Fcj Opto Gjsfjbv Duplex Double Tube Spiral Armored Cable Fiber Optic Cable
Zhejiang Fuchunjiang Photoelectric Science Technology Co., Ltd.- Application：Communication
- Type：Single-mode Fiber
- Connection Structure：Can Be Customized
- Allowed Lateral Pressure：100(N,100mm)<1000(N,100mm)
- Allowed Tensile Strength：1000N<10000N
- Core：Multicore
Base Info
- Model NO.：GJSFJBV Duplex
- Certification：RoHS, UL, CE, ISO9001, VDE, CCC
- Brand：Fcj Opto Tech
- Sheath Material：Lzsh
- Jacked Color：Blue, Orange, Green, White etc.
- Temperature Range：-20~70 Degree
- Transport Package：Carton Box
- Specification：2KM, 3KM
- Trademark：Fcj Opto Tech.
- Origin：China
- HS Code：854470000
- Production Capacity：8000km,Month
Description
Bandwidth
(Class A)@ 850 ≥ 500MHZ · km ≥ 500MHZ · km @ 1300 ≥1000MHZ · km ≥600MHZ · km Numerical aperture 0.200 ± 0.015NA 0.275 ± 0.015 NA Cable cut-off wavelength ≤1260nm ≤1480nm
Technical Parameters
Environmental Characteristics
Storage/Operating Temperature : -20ºC to + 60ºC
(Class A)
Technical Parameters
| Cable Type | Fiber Count | Tight Diameter mm | Cable Diameter mm | Cable Weight Kg/km | Allowable Tensile Strength Long/Short Term N | Allowable pressure Crush Resistance Long/Short Term N/100m | Bending Radius Static/Dynamic mm |
| GJFJV+SV | 72 | 3.0 | 14.0 | 42 | 300/750 | 200/1000 | 20D / 10D |
| GJFJV+SV | 144 | 3.0 | 18.0 | 65 | 300/750 | 200/1000 | 20D / 10D |
Environmental Characteristics
| Transport temperature | -20 ºC ~ +60 ºC |
| storage temperature | -20 ºC ~ +60 ºC |
| Installation temperature | -5 ºC ~ +50 ºC |
| Operating temperature | -20 ºC ~ +60 ºC |
