TUV 0.6/1kv Fg18m16 Single Core Power Cable LSZH 1.5mm2 up to 240mm2

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Fixed Installation
  • Conductor Material：Copper
  • Sheath Material：LSZH
  • Insulation Material：Hepr

Base Info

  • Model NO.：FG18M16 Cable
  • Material Shape：Round Wire
  • Range of Application：LSOH
  • Certification：ISO9001, CE, RoHS
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemTUV Certified FG18M16 CableConductorFlexible annealed plain copperInsulationHEPR, hard ethylene-propylene-rubberOuter SheathLSZH compound Core NumberSingle CoreSpecifications1.5mm2 up to 240mm2Nominal Voltage600/1000VTest voltage4000VTemperature RangeMin. Installation Temperature:  +5°C
Min. Operating Temperature: -20°CMinimum bending radius4÷ 6 x ØColorOptionalCertificationTUVCharacteristicHigh Flexible
Flame Retardant
Fire Resistant
No-toxic
Halogen-Free
No Smoke
LSZH
Reduced Emission of Corrosive GasesApplicationSingle core power cables, rubber insulated (G18), M16 thermoplastic sheathed, with flexible conductors for fixed installation. Fire retardant with low emission of smoke and toxic and corrosive gases and fumes (non-toxic - halogen-free - LSOH).
Suitable for bundle installations in environments with high risk in case of fire for the high population density or for the long time for displacement, or for the high damage to animals and things such as, for example, air terminals, railway stations, harbour stations, subways, road and rail tunnels.
Cables suitable for indoor or outdoor environments, even wet, for fixed installation in laying air, in pipes or ducts, on masonry, metal structures or suspended; buried installation allowed.
