All Dielectric Self-Supporting ADSS Fiber Optic Cable
Qingdao Powtech Electronics Co., Ltd.- Application：Communication
- Type：Single-mode Fiber
- Connection Structure：ADSS
- Material Shape：Round Wire
- Allowed Lateral Pressure：>1000(N,100mm)
- Allowed Tensile Strength：1000N<10000N
Base Info
- Model NO.：ADSS
- Core：Multicore
- Certification：RoHS, UL, ISO9001, VDE, CCC
- Brand：Powtech or OEM
- Sheath Material：PE Sheath
- Fiber Count：48
- Fiber Per Tube：12
- Fiber Type：G652D
- Span：50~1500m
- Loose Tube：PBT
- Outer Sheath：HDPE or at
- Transport Package：Plywood Drum
- Specification：IEEEP1222, SGS, ISO
- Trademark：Powtech
- Origin：Qingdao, China
- HS Code：85477000
- Production Capacity：500km,Month
Description
Notes: The use of power corrosion resistant sheaht is depended on power of ADSS optical fiber cable
HDPE shealth is used when power is less than or equal to 12KV;
Power corrosion resistant sheath (AT sheath) is used when power is more than 12KV.
ADSS fiber optic cable laying mode: Self supporting overhead
ADSS fiber optic cable operation temperature: -40C~ +65 degreeC
Features:
.Small cable Dia, light weight, 1,500m span, low attached load on tower.
.Tension strength is over 90KN.
.Non-metal structure, good insulation, anti-thunder.
.Fine production technology, even force for aramid fiber, with superior stress flexibility
.Anti gun fire
.Anti electro-corrosion.
.Adapt for bad climate.
.May construct without power cut, a power line failure doesn't influence cable's normal transfer.
Tension units are elastic modulus aramid fiber.
.Electric trace resistant outer sheath is adopted to run safely under a circumstance of space electric field (E) ≤25KV/m.
Application:
.Erect on the same pole with power line in new and old power line.
.A long span
.Areas of strong electric field, multi-thunder, etc
