Msha Slywv-75-10 VHF Leaky Feeder Cable with Low Smoke Zero Halogen (LSZH) Outer Jacket for Tunnel, Mine Communication
ZHEJIANG LIBO INDUSTRIAL CO., LTD.- Application：Local Communication Cable, Coaxial Cable
- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：PVC
- Type：Leaky Feeder Cable
- Material Shape：Wire
- Conductor Type：Solid
Base Info
- Model NO.：Leaky Feeder Cable
- Wire Core Material：Bare Copper
- Certification：CE, ISO
- Model：Slywv-75-10
- Brand：Libo
- Transport Package：350m,500m,1000m
- Specification：Leaky Feeder Cable
- Trademark：Libo
- Origin：China
- Production Capacity：1000 Km Per Month
Description
Inner conductor
2.31mm bare copper
Dielectric
9.50mm
Outer conductor
16x0.6 bare copper wire
Outer jacket
15.0mm+/-0.2mm
Frequency
5 to 500MHZ
impedance
75 ohms
Attenuation @160 MHZ
4.2dB/100m
DC resistance inner conductor
<4.5 ohm/km
DC resistance outer conductor
<4.1 ohm/km
capacitance
54 pF/m
Insulation resistance
>10.4m ohm/km
MIN. bend radius
150mm
Operating temperature
-40 to +70 centigrade
Competitive Advantage:
- Libo cable was established in 1994, it covers over 340,000 square meters on our operating area.
- Libo cable has a stable workforce and engineering team, our production and testing procedures are all strictly follow requirement of ISO9000, and ISO14000.
- Libo cable is equipped with a Provincial-level Research and Development Center; we offer OEM and ODM services.
- Over 10 years of experience on leaky feeder cable, big market share in oversea leaky feeder cable industry.
