200c 600 V Silicone Insulation Fiberglass Braided Heating Electric Heating Wire
Yangzhou Fongming Cable Factory- Type：Insulated
- Conductor Type：Stranded
- Application：Heating
- Conductor Material：Tinned Copper
- Sheath Material：Silicone
- Insulation Material：Silicone Rubber
Base Info
- Model NO.：UL3074
- Material Shape：Round Wire
- Range of Application：High Temperature Element
- Certification：ISO9001, UL, CCC, RoHS, SGS CTI
- Brand：Fongming
- Name：200c 600 V Silicone Rubber Fiberglass Braided Heat
- Temperature Range：-60deg.C-200deg.C
- Color：Optional Red White Blue Black Wire
- Sample：3-8meters Free
- MOQ：1000m
- Voltage：300,500V
- Customize：Available
- Lead Time：Normaly 7 Days
- UL File No.：E315207
- Manufacturer：Yangzhou Fongming Cable Factory
- Country of Origin：Yangzhou, China
- Name1：UL3074 Wire
- Name2：Silicone Fiberglass Wire
- Transport Package：Cartons and Pallet
- Specification：AS CUSTOMER REQUIREMENT
- Trademark：FONGMING
- Origin：Yangzhou China
- HS Code：8544492100
- Production Capacity：100000000meters Per Month
Description
Basic Info.
Model NO. UL3074 Material Shape Round Wire Range of Application High Temperature Element Certification ISO9001, UL, CCC, RoHS, SGS CTI Brand Fongming Name 200c 600 V Silicone Rubber Fiberglass Braided Heat Temperature Range -60deg.C-200deg.C Color Optional Red White Blue Black Wire Sample 3-8meters Free MOQ 1000m Voltage 300/500V Customize Available Lead Time Normaly 7 Days UL File No. E315207 Manufacturer Yangzhou Fongming Cable Factory Country of Origin Yangzhou, China Name1 UL3074 Wire Name2 Silicone Fiberglass Wire Transport Package Cartons and Pallet Specification AS CUSTOMER REQUIREMENT Trademark FONGMING Origin Yangzhou China HS Code 8544492100 Production Capacity 100000000meters Per MonthProduct Description
200c 600 V Silicone Insulation Fiberglass Braided Heating Electric Heating WireDescription
Ratings: 200°C-300/ 500Volts-60245
Model No. UL3068, UL3069, UL3071, UL3074, UL3075, UL3122, UL3304
CONSTRUCTION
Conductors: Stranded tinned copper
Insulating: Silicone rubber
Outer Sheath: Fiberglass braid with high temperature finish
Color : Natural and Solid Colors, With UL standard surface marking.
CHARACTERISTICS
Suitable for applications to -60°C
Excellent and flexible cable.
APPLICATIONS
Used for internal wiring of commercial, industrial,household ovens and lighting fixture.
Ideal for use in electric heaters and for equipment wiring as high temperature lead wire.
Suitable for application to -60°C.
Specification
Rating | 200 deg C, 600 Vac, Horizontal flame. |
Conductor | 18 AWG - 13 AWG, solid or stranded. |
Insulation | Extruded SR, 0.76mm minimum average thickness, 0.69mm minimum thickness at any point. |
Covering | Same as for Type SF-2 (Fixture Wire UL 66). |
Standard | Appliance Wiring Material UL 758. |
Marking | General. |
Use | Internal Wiring of Appliances. |
Certificates
Transport & Payment
Packing: 305m per roll or spool, carton packing or add wooden pads.
Shipping: tansport bysea or by air.
As the customers requirements.
Port: Shanghai Port, Ningbo Port, Lianyungang Port, ShenZhen port.
Company Information
Yangzhou Fongming Cable Factory, located in BaoYing, North of YangZhou, which is a historical, cultural and celebrated city in China, is a professional manufacturer producinguniversal and special Cables& Wires including UL High Temperature Wires, Multi-layers Fiber Glass Braided Wires, PTFE trapped Wires, Automobile Sensor Cables, HID Cables, High Voltage Wires for Auto etc.
We have gained certificates for China Compulsory Product Certification(CCC), ISO9001International Quality System Certification , American UL , SGS and CTi. With an experienced and professional team, our products have been covered to many regions in China and mainly exported to European and American Markets.
Factory Size (Sq.meters): | 45,000-50,000 square meters |
Factory Location: | Industrial Avenue,Industrial Center,Xiaji Town Baoying Country ,Yangzhou Jiangsu,China |
Number of Production Lines: | 20 |
Number of R&D Staff: | 21 - 30 People |
Number of QC Staff: | 21 - 30 People |
Contract Manufacturing: | OEM Service Offered Design Service Offered Buyer Label Offered |
FAQ
1. Why the price is so low?
You are ordering directly from the factory.
2.Where is your factory located? How can I visit there?
Our factory is located in Yangzhou City, Jiangsu Province, China,which is near Shanghai. All our clients, from home or abroad, are warmly welcomed to visit us.
3.Can I get some samples?
Yes, we are honored to offer you samples.
4. Can you make the products with my design?
Yes. customization is welcome .
