E2000/APC-LC/APC Singlemode Simplex Optical Fiber Patch Cord 3.0mm PVC 3 Meters
Telefly Telecommunications Equipment Co., Ltd.- Application：Communication, Sensor
- Type：Single-mode Fiber
- Connection Structure：E2000,APC-LC,APC
- Material Shape：Round Wire
- Allowed Lateral Pressure：>1000(N,100mm)
- Allowed Tensile Strength：1000N<10000N
Base Info
- Model NO.：TFL-SM-E-LC-1-01
- Core：Single Core
- Certification：RoHS, UL, CE, ISO9001, CCC
- Brand：Telefly or OEM
- Sheath Material：PVC(Ofnr)
- Transport Package：Plastic Bags in Carton
- Specification：3 meter long or any length as required
- Trademark：Telefly or OEM
- Origin：Shenzhen, China
- HS Code：8544700000
- Production Capacity：10000PCS,Month
Description
Parameter
type
PC
SPC
UPC
APC
Insertion Loss
SM
≤0.20dB
≤0.20dB
≤0.20dB
≤0.25dB
MM
≤0.30dB
≤0.30dB
≤0.30dB
≤0.30dB
Return Loss
SM
≥50dB
≥50dB
≥50dB
≥60dB
MM
≥40dB
≥40dB
≥40dB
≥40dB
Mating Durability(500 timer)
Additional Loss≤0.1dB, Return Loss Variability<5dB
Temperature Stability(-40°C~85°C)
Additional Loss≤0.2dB, Return Loss Variability<5dB
Operating Temperature
-40°C~+85°C
LC Connector Technical Parameters
| Insertion loss | Typical value≤0.15dB;Maximum≤0.20 |
| Return loss | ≥ 60dB (APC);≥ 50dB (UPC) |
| Endurance | 500 matings |
| Vibration | Frequency: 10 to 55Hz, Amplitude: 0.75mm |
| Cable retention | 100N (patch cable); 5N (pigtail) |
| Cold | -25°C, 96h duration |
| Dry heat | +70°C, 96h duration |
| Change of temperature | -25°C to +80°C, 12 cycles |
| Humidity | +40°C at 93%, 96h duration |
Company Information
Telefly is one of the major fiber optic component suppliers in China (adapters, patch lines, braids, attenuators, shunt media converters, etc.), industrial switches, indoor and outdoor fiber optic equipment for more than 10 years. Our products have been exported to more than 30 countries. I'm honored to work with you for a long-term and win-win cooperation between our two companies.
