CE Certified Flexible Flame Retardant Je-Lihch Bd Data Cable

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：Halogen-Free Compound
  • Insulation Material：Polymer Compound
  • Material Shape：Round Wire

Base Info

  • Model NO.：JE-LiHCH Bd
  • Range of Application：Flame Retardant
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemCE Certified Flexible Flame Retardant JE-LiHCH Bd Data CableConductorBare copperInsulationPolymer compoundWrappingFoilScreenCopper braidedOuter SheathHalogen-free compoundNominal Voltage225 V (not for heavy current installation purposes)Test VoltageCore/core 500 V
Core/screen 2000 VTemperature RangeFlexing -5°C to +50°C
Fixed installation -30°C to +70°CMinimum bending radius7.5 x cable ØColorOptionalApplicationHalogen-free installation cables with improved characteristics in the case of fire are used for telephone transmission, measuring and signal purposes. The copper screened design (C) protects the transmission circuits against electrical interferences. A fire propagation is prevented through high oxygen index of the insulation material and produce no corrosive gases in case of fire. They are preferably used for telecommunication installations insidebuildings. These cables are suitable for fixed installation in areas with danger of fire, in dry and damp environments as well as in and under plaster.
