Trommelflex PUR-Hf Halogen-Free Reeling Cable 0, 6/1 Kv

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：Polyurethane
  • Insulation Material：Polyester
  • Material Shape：Round Wire

Base Info

  • Model NO.：TROMMELFLEX PUR-HF
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemTROMMELFLEX PUR-HF Halogen-free Reeling Cable 0,6/1 kVConductorBare copper strandInsulationBased on polyesterInner sheathPolyurethaneAnti-torsion braidWide-meshed polyester braidOuter SheathPolyurethaneOperat. temp. fixed min/max -50 °C / +90 °COperat. temp. moved min/max-40 °C / +90 °CTemp. at conductor +90 °CNominal VoltageUo/U: 0,6/1 kVColorOptionalCertificationCEApplicationHalogen-free reeling cable for heavy duty devices such as cable reels (also vertical operation), hoisting devices, conveyor facilities, mobile motors, rail motors and agricultural devices. For exceptional mechanical stress in dry, humid and wet rooms and for outdoor use.
