• Material Shape：Round Wire
• Range of Application：UV-Resistance
• Certification：ISO9001, CE, CCC
• Brand：Yifang
• Voltage：600,1000V
• Standards：ANSI,Icea S-70-547, ANSI,Icea S-76-474, NFC 33-209
• Transport Package：Wooden Drums, Steel Drums, Steel-Wooden Drums etc.
• Origin：China
• HS Code：8544492100
• Production Capacity：50, 000km Per Year

Basic Info.

Material Shape Round Wire Range of Application UV-Resistance Certification ISO9001, CE, CCC Brand Yifang Voltage 600/1000V Standards ANSI/Icea S-70-547, ANSI/Icea S-76-474, NFC 33-209 Transport Package Wooden Drums, Steel Drums, Steel-Wooden Drums etc. Origin China HS Code 8544492100 Production Capacity 50, 000km Per Year

Product Description

600/1000V UV Resistance Aluminum Conductor XLPE Insulated Cable

Application:
Used primarily for overhead and distribution line, or to supply 120/220V aerial service for tem service at construction sites, as a service drop(power pole to service entrance) as a secondary cable(Pole to Pole), or street lighting. For service at 1000V or lower at a maximum conductor temperature of 75ºC or 90ºC

Applicable standards:
ANSI/ICEA S-70-547, ANSI/ICEA S-76-474, NFC 33-209, IEC60502-1, BS7870.50, VDE 027-626

Production Scope:
Phase Core:  1 to 6 Cores, Cross section from 6AWG to 500MCM
Bare Neutral: Cross Section from 6AWG to 500MCM
Construction:
Phase Core:
Conductor: Hard bare copper/Aluminum/Aluminum alloy etc.
Insulation: PVC/XLPE/PE
Neutral Conductor (optional):  ACSR /AAAC/AAC
Insulation: PVC/XLPE/PE
Street Lighting core (optional):
Conductor: AAC
Insulation: PVC/XLPE/PE

* We can design and produce according to client's requirement.
