Mining Coal Cable Copper Mining Mobile Screened Rubber Sheath Soft Cable Waterproof Rubber Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type:Insulated
- Conductor Type:Stranded
- Application:Underground
- Conductor Material:Copper
- Sheath Material:Rubber
- Insulation Material:Rubber
Base Info
- Model NO.:Myp 0.66,1.14kv
- Material Shape:Round Wire
- Range of Application:Mine
- Certification:ISO9001, CE, UL, CCC, RoHS, VDE
- Brand:Feiya
- OEM:Yes
- Transport Package:Wooden Box Packing or Pallet Shipping Containers
- Specification:copper
- Trademark:Feiya
- Origin:China
- HS Code:854449210
- Production Capacity:80000 Meter,Meters Per Month
Description



YFFB Series Cable is special designed for frequent motion and flexing. This cable
can be used for festoon systems, power tracks, cable tenders, cranes and hoists.
Feature:
Sheath: Special polychloreprene (Butadiene-Acrylonitrile Rubber) which is flame
resistance and self-extinguishing.
Conductor: Superfine Soft Bare Copper which purity can reach 99.999%.
Insulation: Special polychloreprene (Butadiene-Acrylonitrile Rubber)
Technical data:
Rated voltage: ≤1.5mm2 300/500V >1.5mm2: 450V/750V
Test voltage: ≤1.5mm2 2500V >1.5mm2: 3000V
Temperature range: -20°C to +80°C
Model | Qty of Cores | Section of Cores mm2 | Width of Cable mm | Thickness of Cable mm | Weight kg/km |
YFFB | 4 | 1.5 | 16.3 | 5.8 | 198.4 |
YFFB | 4 | 2.5 | 18.7 | 6.6 | 268.4 |
YFFB | 4 | 4 | 21.9 | 7.3 | 367.7 |
YFFB | 4 | 6 | 26.9 | 8.0 | 507.6 |
YFFB | 4 | 10 | 34.5 | 9.7 | 784.1 |
YFFB | 4 | 16 | 38.5 | 10.7 | 1074 |
YFFB | 4 | 25 | 47 | 12.8 | 1575 |
YFFB | 4 | 35 | 56.6 | 15.2 | 2245 |
YFFB | 6 | 1.5 | 23.3 | 5.8 | 282.8 |
YFFB | 6 | 2.5 | 26.9 | 6.6 | 386.5 |
YFFB | 6 | 4 | 31.7 | 7.3 | 534.2 |
YFFB | 6 | 6 | 38.7 | 8.0 | 737 |
YFFB | 6 | 10 | 50.1 | 9.7 | 1148 |
YFFB | 6 | 16 | 56.1 | 10.7 | 1580 |
YFFB | 6 | 25 | 68.6 | 12.8 | 2322 |
YFFB | 6 | 35 | 82.6 | 15.2 | 3311 |
YFFB | 8 | 1.5 | 29.3 | 5.8 | 358.8 |
YFFB | 8 | 2.5 | 36 | 6.6 | 513.3 |
YFFB | 8 | 4 | 40.5 | 7.3 | 690 |
YFFB | 8 | 6 | 48.9 | 8.0 | 947.7 |
YFFB | 8 | 10 | 63.9 | 9.7 | 1486 |
YFFB | 8 | 16 | 71.9 | 10.7 | 2057 |
YFFB | 8 | 25 | 88.2 | 12.8 | 3031 |
YFFB | 10 | 1.5 | 35.3 | 5.8 | 434.7 |
YFFB | 10 | 2.5 | 41.3 | 6.6 | 603.3 |
YFFB | 10 | 4 | 49.3 | 7.3 | 845.9 |
YFFB | 10 | 6 | 59.1 | 8.0 | 1158 |
YFFB | 10 | 10 | 77.7 | 9.7 | 1824 |
YFFB | 10 | 16 | 87.7 | 10.7 | 2535 |
YFFB | 12 | 1.5 | 41.3 | 5.8 | 51.7 |
YFFB | 12 | 2.5 | 48.5 | 6.6 | 711.8 |
YFFB | 16 | 1.0 | 47.1 | 4.8 | 475.5 |
YFFB | 16 | 1.5 | 54.3 | 5.8 | 671 |
YFFB | 16 | 2.5 | 63.9 | 6.6 | 838.3 |
YFFB | 20 | 1.0 | 58.3 | 4.8 | 587.9 |
YFFB | 20 | 1.5 | 67.3 | 5.8 | 831.4 |
YFFB | 20 | 2.5 | 79.3 | 6.6 | 1165 |
