High Quality Coaxial Cable 50 Ohm Rg213 Cable
Hangzhou Xingfa Technology Co., Ltd.- Application:Coaxial Cable
- Conductor Material:BC,CCS,CCA,TC,CU,CCAG
- Cover Material:PVC
- Type:Coaxial
- Material Shape:Round Wire
- Conductor Type:Solid
Base Info
- Model NO.:rg213 cable
- Wire Core Material:Bare Copper Wire
- Certification:CE, ISO, RoHS, UL
- Model:Rg213 Cable
- Brand:Xingfa
- Cable Type:Rg213 Cable
- Inner Conductor:7,0.75 mm Stranded Bare Copper
- Dielectric:7.25 mm Solid Polyethylene
- Shield:Bare Copper 90% Coverage
- Jacket:10.3 mm Black PVC
- Color:Black
- Transport Package:305M WOODEN SPOOL
- Specification:CE. ROHS, UL, ETL
- Trademark:XINGFA or OEM
- Origin:CHINA
- HS Code:85442000
- Production Capacity:300,000km
Description
Construction
Center Conductor: 7*0.75mm Strand copper
Dielectric: 7.25mmSolid PE
Braid: Tin/BC Copper
Braid Coverage: 95%
Jacket: 10.1mm+0.1mmPVC
Characteristics
Sparker Test: 4000VAC
Impedance: 50+3 Ohm
Capacitance: 30.8+3pF/m
Velocity of Propagation: 66.0%
Attenuation {@68 * F.(20 * C.)}
Attenuation:
Frequency (MHz) Maximum (dB/100 ft.)
100 2.20
400 4.60
1000 9.00
Packing
1) Packing Lengths:100/roll,200m/roll,300m/roll,305m/roll
2) Inner Packing:Wooden reel,plastic reel,and paper reel
3) Outer Packing:Carton box,pull out box,pallet available
More Cables & Products
Cables:
1) 75 ohm Coaxial Cable RG6, RG59, RG11;
2) 50 ohm Coaxial Cable RG174, RG58, RG8, RG213, RG214;
3) Siamese CCTV Cable RG59+2C, KX6+2C, RG6+2C;
4) Combo Coaxial Cable RG6+Cat5e, RG6+CAT5E+Messenger etc;
5) LAN Cable/Network Cable UTP/FTP Cat5e, Cat6, Jumper Cable;
6) 1 pair/2 pairs Telephone Cable;
7) Security Alarm Cable, Fire Alarm Cable, Speaker Cable;
8) Optical Fiber Cable (GYXTY, GYXTW, ADSS, FTHH etc.);
9) 50 ohm RF Feeder Cable 1/4"S, 3/8"S, 1/2"S, 1/2", 7/8", 1-1/4", 1-5/8".
Cable Related Products:
1) Coaxial Cable Connector (F, BNC, RCA, Female, Male);
2) Cable Crimping Tool, Wire Stripper, Insertion Punch Tool;
3) Optical Transmission Equipments, CATV amplifier, Taps, Splitters.
