UL3069 Fiberglass Braided Silicone Rubber Wire
Jiangyin Yuanda Electrical Material Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Heating, Underground
- Conductor Material：Tinned Copper
- Insulation Material：Silicone Rubber
- Certification：ISO9001, UL, CCC, RoHS, VDE
Base Info
- Model NO.：ul3069
- Spec AWG：30-16
- Color：as The Customer Requires
- MOQ：5000 Meters
- Delivery：Within 25 Days
- Certificate：E216252 CSA229260
- Transport Package：Pallet,Carton,Tray,Reel
- Specification：ISO9001, UL, CCC, RoHS, VDE
- Trademark：Yuanda
- Origin：Wuxi, China
- Production Capacity：1000km,Day
Description
| Conductor | Insulation | |||||
| spec AWG | Conductor construction No./mm | Diameter mm | Nominal thickness(mm) | Fiberglass thickness(mm) | Nominal diameter (mm) | Max diameter (mm) |
| 26 | 7/0.16 | 0.48 | 0.8 | 0.15 | 2.4 | 2.6 |
| 24 | 7/0.20 | 0.6 | 0.8 | 0.15 | 2.5 | 2.7 |
| 22 | 7/0.25 | 0.75 | 0.8 | 0.15 | 2.8 | 3.1 |
| 20 | 7/0.31 | 0.93 | 0.8 | 0.15 | 3 | 3.3 |
