UL3231 Fiberglass Braided Silicone Rubber Wire
Jiangyin Yuanda Electrical Material Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Heating, Underground
- Conductor Material：Tinned Copper
- Insulation Material：Silicone Rubber
- Certification：ISO9001, UL, CCC, RoHS, VDE
Base Info
- Model NO.：ul3231
- Spec AWG：30-16
- Color：as The Customer Requires
- MOQ：5000 Meters
- Delivery：Within 25 Days
- Certificate：E216252 CSA229260
- Transport Package：Pallet,Carton,Tray,Reel
- Specification：ISO9001, UL, CCC, RoHS, VDE
- Trademark：Yuanda
- Origin：Wuxi, China
- Production Capacity：1000km,Day
Description
| Conductor | Insulation | |||||
| spec AWG | Conductor construction No./mm | Diameter mm | Nominal thickness(mm) | Fiberglass thickness(mm) | Nominal diameter ( mm ) | Max diameter ( mm ) |
| 26 | 7/0.16 | 0.48 | 0.78 | 0.15 | 2.4 | 2.6 |
| 24 | 7/0.20 | 0.60 | 0.78 | 0.15 | 2.5 | 2.7 |
| 22 | 7/0.25 | 0.75 | 0.78 | 0.15 | 2.8 | 3.1 |
| 20 | 7/0.31 | 0.93 | 0.78 | 0.15 | 3 | 3.3 |
| 18 | 7/0.395 | 1.19 | 0.78 | 0.15 | 3.2 | 3.5 |
| 16 | 7/0.495 | 1.49 | 0.78 | 0.2 | 3.6 | 3.9 |
| 14 | 41/0.25 | 1.82 | 0.78 | 0.2 | 4 | 4.5 |
| 12 | 45/0.32 | 2.5 | 0.78 | 0.25 | 5.2 | 5.7 |
| 10 | 35/0.45 | 3.08 | 1.18 | 0.25 | 6 | 6.5 |
| 8 | 44/0.50 | 3.9 | 1.53 | 0.4 | 7.8 | 8.5 |
| 6 | 70/0.50 | 5.5 | 1.53 | 0.4 | 9.4 | 10.3 |
| 4 | 110/0.50 | 6.9 | 1.53 | 0.4 | 10.8 | 11.8 |
| 2 | 175/0.50 | 8.7 | 1.53 | 0.4 | 12.6 | 13.8 |
| 1 | 217/0.50 | 10 | 2.03 | 0.5 | 15.1 | 16.6 |
| 1/0 | 276/0.50 | 11.2 | 2.03 | 0.5 | 16.3 | 17.9 |
| 2/0 | 342/0.50 | 12.2 | 2.03 | 0.5 | 17.3 | 18.9 |
| 3/0 | 437/0.50 | 13.8 | 2.03 | 0.5 | 18.9 | 20.7 |
| 4/0 | 551/0.50 | 15.5 | 2.03 | 0.5 | 20.6 | 22.6 |
| 250Kcmil | 1009/0.40 | 16.8 | 2.45 | 0.5 | 22.9 | 25.2 |
| 300Kcmil | 1216/0.40 | 18.5 | 2.45 | 0.5 | 24.6 | 27.1 |
| 350Kcmil | 1406/0.40 | 20 | 2.45 | 0.5 | 26.1 | 28.7 |
| 400Kcmil | 1615/0.40 | 21.5 | 2.45 | 0.5 | 27.6 | 30.3 |
| 450Kcmil | 1813/0.40 | 22.6 | 2.45 | 0.7 | 28.9 | 31.8 |
| 500Kcmil | 2010/0.40 | 23.9 | 2.45 | 0.7 | 30.2 | 33.2 |
| 550Kcmil | 2220/0.40 | 25 | 2.8 | 0.7 | 32 | 35.2 |
| 600Kcmil | 2420/0.40 | 26.2 | 2.8 | 0.7 | 33.2 | 36.5 |
| 650Kcmil | 1675/0.50 | 27.3 | 2.8 | 0.7 | 34.3 | 37.7 |
| 700Kcmil | 1808/0.50 | 28.2 | 2.8 | 0.7 | 35.2 | 38.7 |
| 750Kcmil | 1935/0.50 | 29.3 | 2.8 | 0.7 | 36.3 | 39.9 |
