Rg58 Coaxial Cable
Hangzhou Spring Electronics Co., Ltd.- Application：Local Communication Cable, Coaxial Cable, LAN Cable, Fiber Optic Cable
- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：PVC
- Type：Rg58
- Material Shape：Round Wire
- Conductor Type：Stranded
Base Info
- Model NO.：rg58
- Wire Core Material：Tinned Wire
- Certification：CE, ISO
- Transport Package：Packed by Carton,Wooden Drum,Wooden Pallet
- Specification：Local Communication Cable, Coaxial Cable, LAN Cab
- Trademark：FUU
- Origin：Made in China
- HS Code：8544200000
- Production Capacity：24000km,Year
Description
RG58 BC TC PVC
50 Ohm coaxial Cable
Construction Parameters:
Inner Conductor
19×0.18mm Copper
Dielectric
2.95mm Solid PE
Shield 1
Nom. 3.50mm Tinned Copper
Jacket
4.95mm PVC
Jacket Thickness
Application
Electrical Characteristics:
Capacitance
101.05 pF/m
Impedance
50 Ω
Velocity of Propagation
0.66
Max Operating Voltage
1900 VMS
Shielding Effectiveness(>dB)
70
RoHS
YES
Mechanical and Envrionmental Properties
Cable bend radius
Operating Temp Range
-20 ºC to 80ºC
Cable diamensions
4.95mm
Attenuation(20ºC):
Frequency (MHZ)
Max Attenuation(dB/100ft)
Max Attenuation (dB/100m)
100
15.10
400
30.80
1000
50.20
Order Informations:
Marking
RG58 50 Ohm COAXIAL CABLE ×××M/FT
Package
Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …
Delivery time
Normally 25 days after received the deposit.
