• Model NO.：YJV32
• Wire Core Material：Bare Copper Wire
• Certification：ISO, CCC, CE
• Model：Electrical Cable BS 5467
• Brand：Yifang Cable
• Sheath Color：Black
• Insulation Color：Red,Yellow,Blue,Black
• Transport Package：Drum or According to Your Request
• Specification：ELECTRICAL CABLE BS 5467
• Trademark：yifang cable
• Origin：China
• HS Code：8544492100
• Production Capacity：500, 000 Meters Per Month

Basic Info.

Model NO. YJV32 Wire Core Material Bare Copper Wire Certification ISO, CCC, CE Model Electrical Cable BS 5467 Brand Yifang Cable Sheath Color Black Insulation Color Red/Yellow/Blue/Black Transport Package Drum or According to Your Request Specification ELECTRICAL CABLE BS 5467 Trademark yifang cable Origin China HS Code 8544492100 Production Capacity 500, 000 Meters Per Month

Product Description

BS5467
Armoured Low Voltage Power Cable
BS5467 is the low voltage armoured power cable for industrial wiring and mains distribution. Designed for installation in duct, clipped directly to a surface, on tray, in basket or in free air they may also be laid direct in ground in free draining soil or embedded in concrete. The design of BS5467 is particularly robust and is well suited to areas at risk of mechanical damage.

Manufacturing standard BS 5467
Conductors: Stranded plain annealed copper wire (class 2) to BS EN 60228.
Insulation: XLPE
Bedding: PVC
Armour: Galvanised Steel Wire Armour (Aluminium Wire Armour for single core)
Sheath: PVC Core Colours: Single core: Brown or Blue
Two core: Brown and Blue
Three core: Brown, Black and Grey
Four core: Brown, Black, Grey and Blue
Five core: Brown, Black, Grey, Blue and Green/Yellow Sheath colour: Black


Voltage rating (U0/U):	600/1000V
Max. Conductor temp	90°C  Note: Where a conductor operates at a temperature exceeding 70°C it  shall be ascertained that the equipment connected to the conductor is  suitable for the conductor operating temperature (see regulation  512-1-5 of BS7671, the 17th Edition of IEE Wiring Regulations)
Min, bending radius	6D circular conductors 8D shaped conductors
Curent rating	Refer to tables 4E4A & 4E4B in BS7671 or ERA 69-30 Part V
