Copper PVC Insulated Electric Cable and Wire 1.5/2.5/4/6/10/16/25/35/50mm2

Henan Hongda Cable Co., Ltd.
  • Type：Insulated
  • Application：Overhead
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：1.5,2.5,4,6,10,16,25,35,50mm2 cable
  • Range of Application：Flame Retardant
  • Certification：ISO9001, CE, CCC, RoHS
  • Insulation：PVC
  • Core：Single,Multi-Cores
  • Standard：IEC,NFC33-209
  • Quality Guarantee：10 Years
  • Sheath Color：Black
  • Mark：Laser Type
  • Manufacture：Yes
  • Sample：Yes
  • Cable Parts：Yes
  • Conductor：Copper,Al Core
  • Transport Package：Wooden Plate
  • Specification：1.5-630sqmm
  • Trademark：Hongda
  • Origin：China, Henan
  • HS Code：8544492100
  • Production Capacity：30000km,Per Months

Description

Solid Type0.51/0.80

300/500V

450/750V

0.68.0Solid, Hard,Suitable for fixed installation0.751/0.970.611.411/1.130.615.21.51/1.380.7212.51/1.780.73241/2.250.84761/2.760.867Stranded Type1.57/0.520.722Stranded, Flexible house wiring, Suitable for indoor applicant.2.57/0.680.7352.519/0.400.83447/0.850.850419/0.520.85167/1.040.871619/0.640.872107/1.351.01181049/0.521.0127167/1.701.01771649/0.641.0184Flexible Type1.530/0.250.722Ultra Flexible, Soft Conductor, Suitable for small power equipment instrument.2.549/0.250.834456/0.300.849684/0.300.8701077/0.401.011716119/0.401.016825189/0.401.2265...

  The cable can be of flame retardance, fire resistance, environment friendly or other property. OEM Available.

Parameter

1.Voltage Uo/U 300/500V 450/750V
2.Max. Permissible Continuous Operation Temperature of The Conductor: 70°C
   Flame-retardant Can be reach 90°C or 105°C
3.The Ambient Temperature Under Installation Should Not Below 0°C
4.Impedance (ohms): 100±2ohm


Packaging&Delivery
Copper PVC Insulated Electric Cable and Wire 1.5/2.5/4/6/10/16/25/35/50mm2 Copper PVC Insulated Electric Cable and Wire 1.5/2.5/4/6/10/16/25/35/50mm2


Packaging Details: Packing Length:100m/roll, 200m/roll, 305m/roll, 500m/roll
Delivery Time:Normally within 10 days (detailly depend on the order quantity)
