• Model NO.：YJLV,NA2XY
• Wire Core Material：Aluminum
• Certification：ISO, CCC, CE, RoHS, UL, VDE
• Model：Yjlv
• Brand：Fengda
• OEM&ODM：Yes
• Rated Voltage：8.7,15kv,6,10kv,12,20kv,18,30kv,21,35kv
• Operating Environment：Underground
• Material：PVC,PE Jacket
• Other Service：Can Be Customized
• Use Place：Power Transmission and Distribution
• Lowsmokezerohalogan：LSZH, Lsoh, Ls0h, Lsfh, Ohls
• Colors：Can Be Customized
• Other Standards：XP 00, Yxv-U (-R), C2xy
• Transport Package：Wooden Box Packing or Pallet Shipping Containers
• Specification：copper,aluminum,pvc
• Trademark：Feiya
• Origin：China
• HS Code：8544
• Production Capacity：80000 Meter,Meters Per Month

TypeDescriptionCore NumberNominal Area (mm²)Copper coreAluminum coreVVVLVThe power cable with pvc insulation, pvc outer sheath11.5-630VYVLYThe power cable with pvc insulation, polyethylene outer sheath2-51.5-500VV22VLV22The power cable with pvc insulation, steel strip armour, pvc inner jacket, pvc outer sheathVV23VLV23The power cable with pvc insulation, steel strip armour, pvc inner jacket, polyethylene outer sheathVV32VLV32The power cable with pvc insulation steel wire armour, pvc inner jacket, pvc outer sheathVV33VLV33The power cable with pvc insulation, steel wire armour, pvc inner jacket, polyethylene outer sheath



Using features:

1. Cable conductor allowed working temperature doesn't exceed 70 ºC in a long term

2. When the short circuit happened (the longest duration is no more than 5 seconds), the highest temperature of the cable conductor does not exceed 160 ºC.

3. The environment temperature should not below 0 ºC when cable laying, To warm up first when the temperature lower than 0 ºC .

4. The minimum bending radius of the multicore-non armoured cable shall not be less than 12 times of the outer diameter of cables, and the minimum bending radius of the mutilcore-armored cables shall not be less than 15 times of the outer diameter of cables. The minimum bending radius of the single core armoured cable shall not be less than 15 times of the outer diameter of cable, and the minimum bending radius of the single core -non armoured cable shall not be less than 20 times of the outer diameter of cable

      NOTE:the above these cables could make to Antiflaming power cable, Fire resistance power cable, LSZH power cable in rated voltage 0.6/1 KV, PVC or XLPE insulated, PVC outer sheath.

Q1: Are you a trading company or manufacturer?

A1: Tianjin Feiya wire & Cable Co., Ltd. is a professional manufacturer.

Q2: What kinds of products does Tianjin Feiya wire & Cable Co., Ltd. Manufacture?

A2: Our products mainly cover low, medium and high voltage (KV) crosslinked polyethylene insulated power cable, PVC insulated power cable, PVC insulated wire (construction cable), control cable, signal cable, rubber cable, coal mine cable, welding cable, ship cable and other related customized cables. These cables are used in Power metallurgy, Oil&Chemical Industry, Nation Defense Power Station, Mine, Port and Architectural Engineering, andother fields.

Q3: Which standards do you comply with when you produce the electrical wires and cables?

A3: We have passed ISO9001: 2000 and ISO140001: 2004. All products conform to GB, IEC, BS, ASTM, VDE JB and UL standards. Besides, we have the ability to design and produce various wires and cables, and customize them for you according to the special requirements of customers (providing OEM services).

Q4: What is your MOQ?
A4: It`s base on the cable type or wire type. Please contact Calder. He will let you know.

Q5: How much the Courier freight will be for the samples?

A5: Courier freight depends on the quantity, weight and carton size and your area.
