Competitive Price CATV CCTV Coaxial Cable RG6
Hangzhou Spring Electronics Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Conductor Material：Copper Clad Steel
- Sheath Material：PVC
- Insulation Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：01
- Certification：ISO9001, CE, RoHS
- Trademark：OEM
- Production Capacity：2000km,Month
Description
Attenuation
[@68o F. (20o C.)]
Frequency (MHz)
Maximum (dB/100 ft.)
Maximum (dB/100 m)
5
0.58
1.9
50
1.5
4.9
100
2.0
6.5
200
2.8
9.2
400
4.1
13.6
700
5.6
18.4
900
6.2
20.3
1000
6.5
21.4
1450
8.0
26.2
1800
8.5
27.9
2100
9.5
31.1
2250
10.0
34.0
3000
11.4
37.5
Examples:
1) RG6 Coaxial Cable 75ohm Dual / Standard shield
1.02±0.01mm CCS Conductor+4.57±0.05mm PE Foam+Bonded Al Foil+80x0.12mm Al Alloy Wire 60% Braid+6.90±0.05mm PVC Jacket
2) RG6 Coaxial Cable 75ohm Tri Shielded
1.02±0.01mm CCS Conductor+4.57±0.05mm PE Foam+Bonded Al Foil+80x0.12mm Al Alloy Wire 60% Braid+Al Foil+6.9mm PVC Jacket
3) RG6 Coaxial Cable 75ohm Quad Shield
1.02±0.01mm CCS Conductor+4.57±0.05mm PE Foam+Bonded Al Foil+80x0.12mm Al Alloy Wire 60% Braid +Double Al Foil+ Al Wire braiding +7.5mm PVC Jacket
4) RG6 Coaxial Cable 75ohm With Messenger
1.02±0.01mm CCS Conductor+4.57±0.05mm PE Foam+Bonded Al Foil+80x0.12mm Al Alloy Wire 60% Braid+6.90±0.05mm PVC Jacket+1.30+0.05mm Messenger
5)OEM
