PVC XLPE Insulated AAC ACSR Conductor Single Core 2c Triplex Spaced 33kv ABC Aerial Twisted Bundle Cable
Henan Hongda Cable Co., Ltd.- Application：Construction, Overhead, Industrial, Power Station, ABC AAC AAAC ACSR Conductor Specification of 3 Cor
- Voltage：Low and Medium Voltage Cable
- Current：AC Cable
- Insulation Material：XLPE
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：BS 7870
- Wire Core Material：Aluminum Conductor
- Certification：ISO, CCC, CE, ABC AAC AAAC ACSR Conductor Specification of 3 Cor
- Model：ABC Cable
- Brand：Henan Hongda
- Insulation Color(S)：Natural , Red , Yellow , Blue , Green etc.
- Outer Sheath Color：Black etc.
- No. of Cores：Twin
- Cross Section：16 mm2
- Packing Length：According to Your Request
- Long‐term Working Temperature：90°c
- Max. Temperature in Short Circuit：160°c ,250°c
- Rated Voltage：33kv
- Design Standard：IEC 60502-1, IEC 60502-2, IEC 60227, IEC 60228
- Warranty：3 Year
- Certificate：ISO 14001 , ISO 9001 , Ohasa 18001 , CCC
- Transport Package：by Sea
- Specification：ABC AAC AAAC ACSR conductor specification of 3 cor
- Trademark：HENAN HONGDA
- Origin：China
- HS Code：85444929
- Production Capacity：3000
Description
JKLGYJ (ACSR/XLPE)10/2 2.706 0.0067 0.67 1.0 7 4120 16/3 1.779 0.0067 0.65 1.2 8.4 6130 25/4 1.131 0.0054 0.54 1.2 9.8 9290 35/6 0.8230 0.0054 0.54 1.4 11.0 12630 50/8 0.5946 0.0046 0.46 1.4 12.9 16870 50/30 0.5692 0.0046 0.46 1.4 14.8 42620 70/10 0.4217 0.0040 0.40 1.4 14.8 23390 70/40 0.4141 0.0040 0.40 1.4 16.7 58300 95/15 0.3058 0.0039 0.39 1.6 17.5 35000 95/20 0.3019 0.0039 0.39 1.6 17.3 37200 95/55 0.2992 0.0039 0.39 1.6 19.7 78110 120/7 0.2422 0.0035 0.35 1.6 18.8 27570 120/20 0.2496 0.0035 0.35 1.6 19.4 41000 120/25 0.2345 0.0035 0.35 1.6 19.4 47880 120/70 0.2364 0.0035 0.35 1.6 21.5 98370 150/8 0.1989 0.0035 0.35 1.8 20.7 32860 150/20 0.1980 0.0035 0.35 1.8 21.4 46630 150/25 0.1939 0.0035 0.35 1.8 21.4 54110 150/35 0.1962 0.0035 0.35 1.8 21.9 65020 185/10 0.1572 0.0035 0.35 2.0 23.1 40880 185/25 0.1542 0.0035 0.35 2.0 23.9 59420 185/30 0.1592 0.0035 0.35 2.0 23.9 64320 185/45 0.1564 0.0035 0.35 2.0 24.5 80190 210/10 0.1411 0.0035 0.35 2.0 24.2 45140 210/25 0.1380 0.0035 0.35 2.0 26.0 65990 210/35 0.1363 0.0035 0.35 2.0 25.4 74250 210/50 0.1381 0.0035 0.35 2.0 25.8 90830 240/30 0.1181 0.0034 0.34 2.2 27.2 75620 240/40 0.1209 0.0034 0.34 2.2 27.2 83370 240/55 0.1198 0.0034 0.34 2.2 27.8 102100
