• Model NO.：H05rn-F Yc
• Material Shape：Round Wire
• Range of Application：Flame Retardant
• Certification：CE, UL, CCC, RoHS, VDE
• Brand：Feiya
• Color：Black Red Yellow, According to Voltage Level
• Whether It Is Environmentally Friendly：Yes
• Whether Quality Inspection：Provide Inspection Certificate
• Standard：Customized According to Specified National Standar
• OEM/ODM：Accepted
• Core：Single Core and Multicore
• Transport Package：Standard Export Packaging
• Specification：International General Specifications
• Trademark：Fengda
• Origin：Tianjin, China(Mainland)
• HS Code：8544492100
• Production Capacity：5000000km,Year

H05RN-F is a harmonized, medium duty, flexible, rubber insulated, black neoprene jacketed multi-conductor 500 volts. European cord. Recommended for use in electrical equipment under low stress in dry, damp or wet areas in indoor or outdoor environments. Commonly used as a connection cable in horticulture tools or workshop tools that might be subject to or in contact with oils and fats. Also suitable for fixed installation in furniture, decorative coverings, wall partitions and pre-fabricated building parts. Max operating voltage in a single or three phase system is Uo/U 318/550 volts. In a direct current system, max operating voltage is Uo/U 413/825 volts. The rubber neoprene outer jacket is weather and ozone resistant making this cable suitable for outdoor use.

Construction:

• Fine bare copper strands
• Strands to VDE-0295 Class-5, IEC 60228 Cl-5
• Rubber core insulation to VDE-0282 Part-1
• Color code VDE-0293-308 and HD 186
• Polychloroprene rubber (neoprene) jacket
• Ozone resistant
• Oil & fat resistant to touch

Technical:

• Working voltage: 300/500 volts
• Testing voltage: 2000 volts
• Flexing bending radius: 7.5 x Ø
• Static bending radius: 4.0 x Ø
• Temp range: -25º C to +60º C
• Flame retardant: IEC 60332.1
• Insulation resistance: 20 MΩ x km

Approvals:

• HD22.4 S3
• VDE-0282 Part-4
• CE Low Voltage Directive 2014/35/EU
• IEC 60245-4
• RoHS compliant
