450/750V Multi-Core Stranded Cooper Cable 2X1.5mm 3X2.5mm 4X2.5mm 5X2.5mm Power Cable
Henan Hongda Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Heating
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：2X1.5mm 3X2.5mm 4X2.5mm 5X2.5mm power cable
- Material Shape：Round Wire
- Range of Application：Housing Construction
- Certification：ISO9001, CE, CCC, RoHS
- Brand：Hongda
- Transport Package：Wooden Palate Wooden Box
- Specification：2X1.5mm 3X2.5mm 4X2.5mm 5X2.5mm power cablemm 10mm
- Trademark：hongda cable
- Origin：Henan China
- Production Capacity：500000
Description
Standards:UL83,CSA C22.2No.75-03,UL1581
Type Size
cores
Conductor OD.
(mm)
InsulationThinkness
(mm)
Insulation OD.
(mm)
Nylon Jacket Thinkness
(mm)
Jacket OD.
(mm)
Weight
(kg/km)
conductor resistance
(Ω/km)
15°C Insulation Resistance
(GΩ.m)
14AWG
1
1.63
0.38
2.39
0.1
2.59
23.53
8.4500
205
12AWG
1
2.05
0.38
2.81
0.1
3.01
35.47
5.3100
175
10AWG
1
2.59
0.51
3.62
0.1
3.82
56.79
3.3430
180
8AWG
7
1.23
0.76
5.22
0.13
5.48
94.30
2.1440
185
6AWG
7
1.56
0.76
6.21
0.16
6.53
145.06
1.3480
155
4AWG
7
1.96
1.02
7.93
0.15
8.23
229.96
0.8481
155
3AWG
7
2.2
1.02
8.65
0.15
8.95
283.71
0.6727
145
2AWG
7
2.47
1.02
9.46
0.15
9.76
351.04
0.5335
130
1AWG
19
1.69
1.27
11.00
0.18
11.36
453.53
0.4230
140
1/0AWG
19
1.89
1.27
12.00
0.18
12.36
557.27
0.3354
130
2/0AWG
19
2.12
1.27
13.15
0.18
13.51
689.97
0.2660
115
3/0AWG
19
2.39
1.27
14.50
0.18
14.86
864.04
0.2110
105
4/0AWG
19
2.68
1.27
15.95
0.18
16.31
1073.00
0.1673
95
250MCM
37
2.09
1.52
17.69
0.2
18.09
1325.85
0.1416
105
350kmcil
37
2.47
1.52
20.35
0.2
20.75
1819.13
0.1011
90
500kcmil
37
2.95
1.52
23.71
0.2
24.11
2554.32
0.0708
75
