Overhead Line Power Aerial Bundled Cables Catenary Wires
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Heating
- Conductor Material：Aluminum
- Insulation Material：XLPE
- Material Shape：Round Wire
Base Info
- Model NO.：ABC CABLE
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, UL, CCC, RoHS, VDE, TUV
- Brand：Fengda
- Colour：Red,Green,Blue,Black,White,as Request
- Flame Test：Yes
- OEM/ODM：Accepted
- Core：Single Core and Multicore
- Factory Type：Manufacturer
- Transport Package：Rolls or According to Cusotmers′ Reques
- Specification：0.12 to 400mm2
- Trademark：FengDa
- Origin：Tianjin, China(Mainland)
- HS Code：8544492100
- Production Capacity：5000000km,Year
Description
6.35/11kV
12.7/22kV
19/33kV
Class 2 stranded round aluminium
Class 2 stranded Aluminium
XLPE (Cross-linked Polyethylene)
Copper Wires or Copper Tape (Light Duty/Heavy Duty)
Copper Wires or Copper Tape
-
Copper Wires or Copper Tape (Light Duty/Heavy Duty)
Copper Wires or Copper Tape
HDPE (High Density Polyethylene)
Galvanised Steel Wires
PhaseApprox. Overall Diameter Max. D. C. Resistance of Conductor at 20 Centigrade AAC+UV-XLPE Compact Conductor UV-XLPE Insulation No. X Normal Cross Section of Cores No. Of Al Wires Overall Diameter Normal Thickness Min. Diameter No. X mm 2 - mm mm mm mm mm Ohm/km 1 X 10 7 4.05 1.0 0.8 6.05 6.05 3.08 1 X 16 7 4.8 1.2 0.98 7.2 7.20 1.91 1 X 25 7 6 1.2 0.98 8.4 8.40 1.20 1 X 35 7 7.0 1.4 1.16 9.8 9.80 0.868 1 X 50 7 8.3 1.4 1.16 11.1 11.10 0.641 1 X 70 19 9.8 1.4 1.16 12.6 12.60 0.443 1 X 95 19 11.6 1.6 1.34 14.8 14.80 0.320 1 X 120 19 13 1.6 1.34 16.2 16.20 0.253 1 X 150 19 14.6 1.8 1.52 18.2 18.20 0.206 1 X 185 36 16.2 2.0 1.70 20.2 20.20 0.164 1 X 240 36 18.4 2.2 1.88 22.8 22.80 0.125 2 X 10 7 4.05 1.0 0.8 6.05 12.10 3.08 2 X 16 7 4.8 1.2 0.98 7.2 14.40 1.91 2 X 25 7 6 1.2 0.98 8.4 16.80 1.20 2 X 35 7 7.0 1.4 1.16 9.8 19.60 0.868 2 X 50 7 8.3 1.4 1.16 11.1 22.20 0.641 2 X 70 19 9.8 1.4 1.16 12.6 25.20 0.443 2 X 95 19 11.6 1.6 1.34 14.8 29.60 0.320 2 X 120 19 13 1.6 1.34 16.2 32.40 0.253 2 X 150 19 14.6 1.8 1.52 18.2 36.40 0.206 2 X 185 36 16.2 2.0 1.70 20.2 40.40 0.164 2 X 240 36 18.4 2.2 1.88 22.8 45.60 0.125 3 X 10 7 4.05 1.0 0.8 6.05 13.07 3.08 3 X 16 7 4.8 1.2 0.98 7.2 15.55 1.91 3 X 25 7 6 1.2 0.98 8.4 18.14 1.20 3 X 35 7 7.0 1.4 1.16 9.8 21.17 0.868 3 X 50 7 8.3 1.4 1.16 11.1 23.98 0.641 3 X 70 19 9.8 1.4 1.16 12.6 27.22 0.443 3 X 95 19 11.6 1.6 1.34 14.8 31.97 0.320 3 X 120 19 13 1.6 1.34 16.2 34.99 0.253 3 X 150 19 14.6 1.8 1.52 18.2 39.31 0.206 3 X 185 36 16.2 2.0 1.70 20.2 43.63 0.164 3 X 240 36 18.4 2.2 1.88 22.8 49.25 0.125 4 X 10 7 4.05 1.0 0.8 6.05 14.64 3.08 4 X 16 7 4.8 1.2 0.98 7.2 17.42 1.91 4 X 25 7 6 1.2 0.98 8.4 20.33 1.20 4 X 35 7 7.0 1.4 1.16 9.8 23.72 0.868 4 X 50 7 8.3 1.4 1.16 11.1 26.86 0.641 4 X 70 19 9.8 1.4 1.16 12.6 30.49 0.443 4 X 95 19 11.6 1.6 1.34 14.8 35.82 0.320 4 X 120 19 13 1.6 1.34 16.2 39.20 0.253 4 X 150 19 14.6 1.8 1.52 18.2 44.04 0.206 4 X 185 36 16.2 2.0 1.70 20.2 48.88 0.164 4 X 240 36 18.4 2.2 1.88 22.8 55.18 0.125
