PVC Singlemode Dx E2000/Upc to LC/Upc Fiber Optic Cable
Shenzhen Shengmeida Communication Co., Ltd.- Application：Communication, Sensor, Medicine, Probe, FTTH
- Type：Single-mode Fiber
- Connection Structure：Sc-LC
- Material Shape：Round Wire
- Allowed Tensile Strength：100N<1000N
- Core：Double Core
Base Info
- Model NO.：E2000,UPC to LC,UPC
- Certification：RoHS, ISO9001
- Sheath Material：PVC
- Return Loss：Upc > 50dB ; APC> 60dB
- Insertion Loss：Il<0.2dB
- Transport Package：Carton
- Specification：Any length are available
- Trademark：SMD
- Origin：China
- HS Code：8544700000
- Production Capacity：200000,Month
Description
Type
Standard,Master
Style
LC,SC,ST,FC.MU,DIN,D4,MPO, SC/APC,FC/APC,LC/APC.MU/APC
Fiber
Singlemode/Multimode
50/125, 62.5/125 (Multimode) OM2&OM1
50/125, 10G (Multimode) OM3
Cable
Simplex, Duplex
Φ3.0mm, Φ2.0mm, Φ0.9mm
PVC or LSZH
Polishing Manner
UPC,SPC,APC (8°& 6°)
Insertion Loss
≤ 0.1dB (For Singlemode Master)
≤ 0.25dB (For Singlemode Standard)
≤ 0.25dB (For Multimode)
Tested by JDS RM 3750
Return Loss
(Singlemode)
UPC ≥ 50dB
SPC ≥ 55dB
APC ≥ 60dB (typ.65dB)
Tested by JDS RM3750
Repeatability
±0.1dB
Operating temperature
-400C to 850C
Geometry Requirement
( Singlemode)
Ferrule Endface Radius
7mm ≤ R ≤ 12mm (For APC)
10mm ≤ R ≤ 25mm (For Standard)
Apex Offset ≤ 30 μm (For Master)
Apex Offset ≤ 50 μm (For Standard)
Undercut -50nm ≤ U ≤ 50nm
Tested by DORC ZX-1
5.Product list
Boot
Connector
Fiber Type
Cable number
Ferrule
Connector
0.9mm
2.0mm
3.0mm
LC
FC
SC
ST
MU
D4
MTRJ
MPO
DIN
9/125um SM
50/125um MM
62.5/125um MM
OM3
OM4
Simplex
Duplex
Multi-fiber
Ribbon
PC
APC
UPC
1M
2M
3M4M
5M
.........
Customized
