TUV Certificated N2xy Cable Electric Cable Multi-Core 3X1.5mm2 3X10mm2 3X50mm2
ItemN2XY CableConductorSolid copper conductorInsulationXLPEBeddingPVCOuter SheathPVCCore NumberMulti-coresNominal Voltage600 / 1000 VOperating temperature rangeDuring installation -5°C to +50ºCFixed Installation: -20°C to +90°CColorOptionalApplicationThese power and fixed wiring cab
-
Low Temperature Resistance N2xch Power Cable CE Certification Multi-Cores
ItemHalogen-Free N2XCH CableConductorBare Copper (as client's required)InsulationSpecial cross-linked thermoplastic insulation(as client's required)Outer SheathSpecial halogen-free sheath (as client's required)Rated Voltage600/1000 VTest Voltage4000 VRated VoltageFlexible installations: -15 ºC~
-
High Quality Kystcuy Cable Lift Control Cable for Medium Mechanical
ItemHigh Quality KYSTCUY Cable Lift Control Cable for Medium MechanicalConductorBare copper strandInsulationPVC, PE (0,5)ShieldCopper braid/wrapped tinned wires; coverage ca. 80%FillerOptionalOuter SheathPVCRated voltage0,5 mm²: - 300 V;>1 mm²: - 300/500 VTest Voltage2500 VOperat. temp.
-
Rov-K XLPE PVC Cable Low in Halogens 0.6/1kv
ItemROV-K Cable ConductorCopper (as client's required)InsulationXLPE (as client's required)Outer SheathPVC(as client's required)Rated Voltage600/1000 VTest Voltage3500 VRated Voltage-15 to +90 º CColorOptionalApplicationExcellent for those installations requiring electromagnetic protection to p
-
H05rr-F Light Rubber-Sheathed Cable for Mechanical Requirements 300/500 V
ItemH05RR-F Light Rubber-sheathed Cable for Mechanical Requirements 300/500 VConductorBare or tinned copper strandInsulationRubber compoundOuter SheathSpecial rubber-compoundOperat. temp. fixed min/max -25 °C / +60 °COperat. temp. moved min/max-25 °C / +60 °CTemp. at conductor+60 &de
-
Cable Manufacturing Flame Retardant N2xy Cable XLPE PVC Environmental Protection
ItemN2XY CableConductorCopper (as client's required)InsulationXLPE (as client's required)Outer SheathPVC (as client's required)Specifications1.5mm2 up to 300mm2Nominal VoltageUo/U:0.6/1KVTest Voltage4000VTemperature RatingDuring installation -5°C to +90ºCFixed Installation: -20°C to +90
-
Trommelflex (K) Nshtou-J / (N) Shtou-J Reeling Cable Tkd Alternative
ItemTROMMELFLEX (K) NSHTOU-J / (N)SHTOU-J Reeling Cable TKD AlternativeConductorBare copper strandInsulationRubber compoundInner sheathSpecial rubber compoundAnti-torsion braidWide-meshed polyester braidOuter SheathSpecial rubber compoundOperat. temp. fixed min/max -40 °C / +80 °COperat. tem
-
LSZH H05Z1Z1-F Indoor General Wiring Cable 300/500V
ItemLSZH H05Z1Z1-F Flexible CableConductorBare copper strandInsulationLSZHOuter SheathLSZHNominal Voltage300/500VMinimum Bending Radius5 x overall diameterTemperature Range+5°C to +70°CColorOptionalCertificationCEApplicationUsed as an indoor general wiring cable primarily for installations i
