• Model NO.：coaxial cable
• Wire Core Material：Bare Copper Wire
• Certification：CE, ISO, RoHS
• Brand：OEM
• Conductor Size：1.02
• Braiding：32,48,64,96,112,128,144
• Transport Package：200m,300m,305m
• Specification：0.8mm Conductor
• Trademark：FUU
• Origin：China
• HS Code：8544200000
• Production Capacity：4000km,Month

Construction Parameters:

Inner Conductor

0.040"/1.02mm/18AWG CCS

Dielectric

0.180"/4.57mm Foamed PE

Shield 1

0.187"/4.75mm Bonded Aluminum Polyproylene

Shield 2

Aluminum braid wire 95% coverage

Jacket

0.268"±0.006"/6.81±0.15mm PVC

Jacket Thickness

0.030"/0.76mm

Application

For Use in Longer CATV Run Lengths

Electrical Characteristics:

Inner Conductor Resistance

The Max. at 20ºC shall be <  87 Ω/km

 26.6Ω/1000ft

Capacitance

52 ±3 pF/m         15.9 ±0.9 pF/ft

Impedance

75 ± 3 Ω

Return loss

between 5 and 1000MHz: > 22dB

Velocity of Propagation

0.85

Sparker Test (VAC)

4

Mechanical and Envrionmental Properties

Cable bend radius

10 times the cable diameter

Operating Temp Range

-20 ºC to 60ºC

Cable diamensions

0.268"±0.006"/6.81±0.15mm PVC

Attenuation(20ºC):

Frequency (MHZ)

Max Attenuation(dB/100ft)

Max Attenuation (dB/100m)

5

0.58

1.90

55

1.60

5.25

83

1.95

6.40

187

2.85

9.35

211

3.05

10.00

250

3.30

10.82

300

3.55

11.64

350

3.85

12.63

400

4.15

13.61

450

4.40

14.43

500

4.66

15.29

550

4.90

16.08

600

5.10

16.73

750

5.65

18.54

865

6.10

20.01

1000

6.55

21.49

Order Informations:

Marking

RG6U CCS CATV COAXIAL CABLE ×××M/FT

Package

300M/Wooden Spool

Delivery time

Normally 25 days after received the deposit.
