Outdoor Shielded Cat 6 Cable
Shanghai Total Industrial Co., Ltd.- Application：Local Communication Cable
- Conductor Material：Copper
- Cover Material：PE
- Type：Cat 6
- Material Shape：Round Wire
- Conductor Type：Stranded
Base Info
- Model NO.：Cat 6
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO
- Model：HYA
- Brand：Total
- Diameter：24AWG
- Transport Package：Standard Export Packing
- Specification：QC
- Trademark：TOTAL
- Origin：Shanghai
- HS Code：85441900
- Production Capacity：10000000m,Month
Description
Conductor
Material
Bare Copper
Size
23 AWG
Construction
1/0.560 ± 0.02 mm
Insulation
Material
Foam-Skin PE
Thickness
Average: 0.414 mm Min. at any point: 0.364mm
Material
1.387 ± 0.05 mm
Colors
Blue/White-Blue , Orange/White-Orange
Green/White-Green , Brown/White-Brown
Elongation
Min. 150 %
Tensile strength
Min. 0.51 Kg/mm²
Shield
Al-Mylar Type
Aluminum foil on outside
Mylar Type
Braid
Material
Tinned Copper
Coverage
Min. 40% (Nom. 48 %)
Sheath
Material
PVC
LSZH
Thickness
Average: 0.54 mm
Average: 0.54 mm
Min. at any point: 0.40 mm
Min. at any point: 0.40 mm
Diameter
7.2 ± 0.3 mm
7.2 ± 0.3 mm
Color
Assorted upon request
Assorted upon request
Elongation
Min. 100%
Min. 125%
Tensile strength
Min. 1.407 Kg/mm²
Min. 0.917 Kg/mm²
168100Aging at 100 for 168Hrs
:50%
Min.elongation retention:50%
:75%
Min.tensile strength retention:75%
Min.elongation
retention:75%
Min.tensile
strength retention:70%
Frequency
MHz
Attenuation
(dB/100 meters at 20),Max.
Next
(dB),Min.
Power sum
(dB),Min.
0.772
67*
64*
1.0
65*
62*
4.0
6.4*
56*
53*
8.0
8.9*
51*
48*
10.0
9.9*
50*
47*
16.0
12.3*
47*
44*
20.0
13.8*
45*
42*
25.0
16.0*
44*
41*
31.25
17.1*
42*
39*
62.5
25.6*
38*
35*
100.0
100MHz
33.0*
32*
125.0
37.4*
34*
31*
