JIS Standard Coaxial Cables (BT3002)

SHG COMMUNICATION TECHNOLOGY (HANGZHOU) LTD.
  • Application：Coaxial Cable
  • Conductor Material：BC,CCS,CCA,TC,CU,CCAG
  • Cover Material：PVC
  • Type：Bt3002
  • Material Shape：Round Wire
  • Conductor Type：Stranded

Base Info

  • Model NO.：BT3002
  • Wire Core Material：Bare Copper Wire
  • Certification：CE, ISO, RoHS, CCC, UL, VDE, Reach
  • Model：Bt3002
  • Brand：Shg
  • JIS：Bt3002
  • Transport Package：10m,15m,20m,25m,40m,50m,100m,200m,300m Reel , Coil
  • Specification：CE, RoHS, UL, ETL, ISO9001
  • Trademark：OEM
  • Origin：China
  • HS Code：85442000
  • Production Capacity：20000km Per Month

Description

Basic Info.

Model NO. BT3002 Wire Core Material Bare Copper Wire Certification CE, ISO, RoHS, CCC, UL, VDE, Reach Model Bt3002 Brand Shg JIS Bt3002 Transport Package 10m/15m/20m/25m/40m/50m/100m/200m/300m Reel / Coil Specification CE, RoHS, UL, ETL, ISO9001 Trademark OEM Origin China HS Code 85442000 Production Capacity 20000km Per Month

Product Description

High quality JIS standard video cable BT3002, BT2001, BT2002, BT2003, coaxial cable, apply for Video surveillance cable system, high performance, quality warranty.
Certificates: ETL, CE, RoHS, ISO9001

1) BT3002 Construction:
0.31mm Bare Copper + 1.95mm Solid PE + 90% 1st copper wires braid + 90% 2ND copper wires braid + 3.55mm PVC Jacket

2) BT3002 combo
BT3002*8 cores, BT3002*16 cores, BT3002*32 cores
BT2001*8 cores, BT2001*16 cores, etc...

3) BT2001 Construction:
7*0.20mm Strand Bare Copper + 2.35mm Solid PE + 93% bare copper wires braid + 4.0mm PVC Jacket

4) BT2002 Construction:
7*0.20mm Strand Bare Copper + 2.35mm Solid PE + 93% 1st bare copper wires braid + 90% 2ND bare copper wires braid + 4.6mm PVC Jacket

5) BT2003 Construction:
0.60mm Strand Bare Copper + 3.85mm Solid PE + 93% bare copper wires braid + 90% bare copper wires braid + 6.60mm PVC Jacket

Characteristics
Spark Test: 4000VAC
Impedance: 75+3 Ohm
Capacitance: 52+/-3pF/m
Velocity of Propagation: 66%
Return Loss 20dB min (5-2300MHz)

Assembly
Assembly usually this cable made composite with 2 cores or 4 cores power wires, and coax plug with BNC connector, power wire plug with DC connectors.

Attenuation Sheet
ModelConstruction
BT2001 7*0.20mm Strand Bare Copper, 2.35mm Solid PE, 93% Bare Copper braid, 4.0mm PVC
BT2002 7*0.20mm Strand Bare Copper, 2.35mm Solid PE, 93% 1st cu braid, 90% 2nd Cu braid, 4.6mm PVC
BT2003 0.60mm Copper, 3.85mm PE Solid, 94% 1st Cu braid, 90% 2nd Cu braid, 6.6mm PVC
BT3002 0.31mm Copper, 1.95mm PE Solid, 90% 1st Cu braid, 90% 2nd Cu Braid, 3.55mm PVC
BT3002 Combo BT3002 * 8 Cores, Bt3002 * 16 Cores, BT3002 * 32 Cores...
 BT2001 * 8 Cores, BT2001 * 16 Cores...
