Nyy Ho1n2-D Copper Conductor Yc Ycw Rubber Insulated Cable 6mm2 10mm 25mm 35mm 50mm 450/750V Cabtyre Sheathed Cable Wire
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Application：Underground
- Voltage：Low and Medium Voltage Cable
- Current：DC & AC
- Insulation Material：Rubber
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：YCW YC H07rn-f H05rn-f
- Wire Core Material：Bare Copper Wire
- Certification：CCC, CE, RoHS, UL, VDE
- Brand：Feiya
- OEM：Yes
- Color：Customize
- Rated Temperature：65 Degree
- Brand Name：Fengda
- Transport Package：Wooden Box Packing or Pallet Shipping Containers
- Specification：Copper,Tinned Copper,CCA
- Trademark：Feiya
- Origin：China
- HS Code：8544492100
- Production Capacity：80000 Meter,Meters Per Month
Description
H07RN-F Cable Construction:
- Conductor: Stranded Bare Copper acc. to IEC 60228, EN 60228, VDE 0295, class 5
- Insulation: Synthetic Rubber, EI4 acc. to DIN VDE 0282 part 1 + HD 22.1
- Conductor Color Coding: acc. to HD 308 (VDE 0293-308)
- Conductor Stranding: from 2 conductors stranded in layers
- Jacket: Synthetic Rubber, EM2 acc. to DIN VDE 0282 part 1 + HD 22.1
- Jacket Color: Black
H07RN-F Cable Technical Data:
- Nominal Voltage: Uo/U 450/750 volts
- Testing Voltage U: 2500 volts acc. to DIN VDE 0282 part 2 + HD 22.2
- Min. Bending Radius: 15 x O.D.
