• Model NO.：Medium Voltage Power Cable
• Wire Core Material：Bare Copper Wire
• Certification：ISO, CCC, CE, RoHS, UL
• Model：Yjv32
• Brand：Rneda
• Certificate：UL Ce TUV BV Kema SABS Psb
• Size：1.5-800mm
• Core：Single 2 3 4 3+1 4+1 3+2
• Conductor：Copper or Aluminum
• Usage：Underground
• Armour：Steel Wire
• Type Conductor：Stranded or Solid
• Transport Package：Wooden & Steel Drum
• Specification：IEC DIN ASTM VDE BS
• Trademark：RNEDA
• Origin：China
• HS Code：8544492100
• Production Capacity：1000km Per Month

TYPE

NAME

Main Application

CU core

AL core

YJV/YJY

YJLV/YJLY

XLPE insulated,PVC/PE sheathed power cable

For laying indoor ,tunnel,canal and underground.Unable to bear external mechanical forces,but bear the traction force during laid

YJV22/YJV23

YJLV22/YJLV23

XLPE insulated,steel tape armored,PVC/PE sheathed power cable

For laying indoor ,tunnel,canal and underground.Able to bear external mechanical forces,but unable to bear large pulling force

YJV32/YJV33

YJLV32/YJLV33

XLPE insulated,thin steel wire armored,PVC/PE sheathed power cable

For laying in shaft,water underground will large difference of level.Able to bear external mechanical forces and moderate pulling force

YJV42/YJV43

YJLV42/YJLV43

XLPE insulated,thick steel wire armored,PVC/PE sheathed power cable

For laying in water and seabed.Able to bear positive pressure and pulling force

6. Advantage:

a. Excellent electric and mechanical characteristics

b. Best Resistance chemical corrosion and heat-ageing,environment stress and flame-retardant

c. Simple in structure,Convenient to use

d. Reduce costs.

British Standard MV cables Voltage Rating

BS6622 - standard British MV cable 6.35/11kV 19/33kV

BS7835 - LSZH British MV cable 6.35/11kV 19/33kV

European standard MV cables Voltage Rating

N2XSY - single copper core XLPE insulated with PVC oversheath 6/10kV 12/20kV 18/30kV

N2XS2Y - single copper core XLPE insulated with PE oversheath 6/10kV 12/20kV 18/30kV

NA2XSY - single aluminium core XLPE insulated with PVC oversheath 6/10kV 12/20kV 18/30kV

NA2XS2Y - single aluminium core XLPE insulated with PE oversheath 6/10kV 12/20kV 18/30kV

N2XSEY - 3 copper core XLPE insulated with PVC oversheath 6/10kV

N2XS(F)2Y - single copper core XLPE insulated with water blocking powder and PE oversheath 6/10kV 12/20kV 18/30kV

N2XS(FL)2Y - single copper core XLPE insulated with water blocking powder and aluminium tape tightly bonded to PE sheath 6/10kV 12/20kV

NA2XS(F)2Y - single aluminium core XLPE insulated with water blocking powder and PE oversheath 6/10kV 12/20kV 18/30kV

NA2XS(FL)2Y - single aluminium core XLPE insulated with water blocking powder and aluminium tape tightly bonded to PE sheath 6/10kV 12/20kV 18/30kV
