• Model NO.：19,33kV Three Core Individual Screened & PVC,SWA,P
• Material Shape：Round Wire
• Range of Application：Flame Retardant
• Certification：ISO9001, CE, UL, CCC, RoHS, VDE
• Brand：Feiya
• Color：Black Red Yellow, According to Voltage Level
• Whether It Is Environmentally Friendly：Yes
• Whether Quality Inspection：Provide Inspection Certificate
• Standard：Customized According to Specified National Standar
• OEM/ODM：Accepted
• Core：Single Core and Multicore
• Transport Package：Standard Export Packaging
• Specification：International General Specifications
• Trademark：Fengda
• Origin：Tianjin, China(Mainland)
• HS Code：8544492100
• Production Capacity：100000,Day

Introduction1Can be customized according to requirements.2Independent brand recruitment agency.3High quality, ISO 9001, CCC, CE, RoHS certified.4ODM&OEM is available.

Product Description

Three-Core Cables, with Copper Conductors, XLPE Insulated, PVC Sheathed, Non-Armored Cable
Application

Suitable for installations indoors: mostly in power supply stations and outdoors: in cable ducts, underground, and on cable trays for industries, switch-boards and power stations. Due to the good laying and mechanical characteristics, this cable is suitable when mechanical protection is required or in applications where mechanical damages are expected to occur.

Standards

It is designed and tested to meet or exceed the requirements of IEC 60502-2 standard and/or BS 6622 standard with rated voltage 19 / 33 (36) kV.

Cable Construction

·Conductor
Plain annealed stranded circular compacted copper conductor (Class 2)

·Conductor Screen
Extruded layer of a cross-linkable semi-conducting compound as a stress control layer

·Insulation
Extruded layer of cross-linked polyethylene (XLPE).

·Insulation Screen
Extruded layer of a cross-linkable semi-conducting compound firmly bonded to the insulation.

·Metallic Screen
Flat plain copper tape helically applied over the insulation screen with suitable overlap.
Note: Copper wire screen is optional.

·Filler
Non-hygroscopic polypropylene filler suitable for the operating temperature of the cable

·Binder
Non Woven Tape.

·Outer Sheath
Extruded layer of Polyvinyl chloride (PVC).
