H05z-K / H07z-K Cross-Linked Thermoplastic Halogen-Free Flame Retardant Polyolefin Single Core Flexible Electric Cables

Tianjin Feiya Electric Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Overhead, Underground
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：Cross-Linked Thermoplastic Halogen-Free Flame Reta

Base Info

  • Model NO.：H05z-K , H07z-K
  • Material Shape：Round Wire
  • Range of Application：Flame Retardant
  • Certification：CE, UL, CCC, RoHS, VDE
  • Brand：Feiya
  • Color：Black Red Yellow, According to Voltage Level
  • Whether It Is Environmentally Friendly：Yes
  • Whether Quality Inspection：Provide Inspection Certificate
  • Standard：Customized According to Specified National Standar
  • OEM/ODM：Accepted
  • Core：Single Core and Multicore
  • Transport Package：Standard Export Packaging
  • Specification：International General Specifications
  • Trademark：Fengda
  • Origin：Tianjin, China(Mainland)
  • HS Code：8544492100
  • Production Capacity：100000,Day

Description

H05Z-K0,516 x 0,202,12,60,61,139,00004,89c.1000,7524 x 0,202,22,80,61,326,00007,213c.100132 x 0,202,42,90,61,519,50009,615c.100H07Z-K1,530 x 0,252,83,50,71,813,300014,424c.1002,550 x 0,253,44,30,82,67,980024,035c.100456 x 0,303,94,90,83,24,950038,451c.100684 x 0,304,45,50,83,93,300057,672c.1001080 x 0,405,77,11,05,11,910096,0120c.10016128 x 0,406,78,41,06,31,2100153,6180CUT25200 x 0,408,410,61,27,80,7800240,0278CUT35280 x 0,409,712,11,29,20,5540336,0375CUT50400 x 0,4011,514,41,411,00,3860480,0560CUT70356 x 0,5013,216,61,413,10,2720672,0780CUT95485 x 0,5015,218,81,615,00,2060912,0952CUT120614 x 0,5016,720,91,617,00,16101152,01200CUT150765 x 0,5018,623,31,819,00,12901440,01600CUT185944 x 0,5020,625,82,021,00,10601776,02100CUT2401225 x 0,5023,529,42,224,00,08012304,03015CUT

Conductor:bare or tinned copper conductor, fine wired stranded, class 5 acc. to HRN HD 383 / IEC 60228 / DIN VDE 0295at some producers:separator between conductor and insulationInsulation:cross-linked thermoplastic halogen-free flame retardant polyolefin bondTemperature range: during installation:-5 °C up to +70 °Cfixed installed:-20 °C up to +90 °Cmax. operating temperature:90 °Cat short circuit of max. 5 s:up to 250 °CNominal voltage: H05Z-K:Uο/U = 300/500 VH07Z-K:Uο/U = 450/750 VTest voltage:2500 VMinimal inner bending radius:6DFlame retardant:IEC 60332-1Halogen-free:IEC 60754-1Non-corrosive combustion gases:IEC 60754-2Low smoke density:IEC 61034-2
