Galvanized Earth Wire BS 183
YIFANG ELECTRIC GROUP INC.- Type：Bare
- Conductor Type：Stranded
- Application：Ground Wire
- Conductor Material：Steel
- Sheath Material：None
- Insulation Material：Bare
Base Info
- Material Shape：Round Wire
- Range of Application：Ground Wire
- Certification：ISO9001
- Brand：Yifang
- Transport Package：Wooden Drum, Steel Drum, Wooden&Steel Drum
- Specification：1mm~10mm
- Trademark：YIFANG
- Origin：Zhengzhou China
- HS Code：7217200000
- Production Capacity：1000 Mt,Month
Description
Approximate strand diameter Simens Martin Grade High Strength Grade Extra-High Strength Grade Approx.weight (inch) mm kN kN kN kg/km 3/2.64 7/32 5.66 10.409 15.569 21.796 131 3/3.05 1/4 6.35 15.523 21.04 29.981 174 3/3.05 1/4 6.35 - - 174 3/3.30 9/32 7.14 15.035 23.398 33.362 204 3/3.68 5/16 7.94 18.193 28.246 40.479 256 3/4.19 3/8 9.25 24.732 37.187 52.489 328 7/1.04 1/8 3.18 4.408 5.916 8.14 49 7/1.32 5/32 3.97 6.539 5.519 13.078 76 7/1.57 3/16 4.76 8.452 12.677 17.748 108 7/1.65 3/16 4.76 - 118 7/1.83 7/32 5.56 11.387 17.126 24.02 145 7/2.03 1/4 6.35 14.012 21.129 29.581 181 7/2.36 9/32 7.14 18.905 28.469 39.812 243 7/2.64 5/16 7.94 23.798 35.586 49.82 305 7/2.77 5/16 7.94 - - 335 7/3.05 3/8 9.52 30.915 48.04 68.503 407 7/3.68 7/16 11.11 41.591 64.499 92.523 594 7/4.19 1/2 12.7 53.823 83.627 119.657 768 7/4.78 9/16 14.29 69.837 108.981 155.688 991 7/5.26 5/8 15.88 84.961 131.667 188.605 1211 19/2.54 1/2 12.7 56.492 84.961 117.768 751 19/2.87 9/16 12.49 71.616 107.202 149.905 948 19/3.18 5/8 15.88 80.513 124.995 178.819 1184 19/3.81 3/4 19.05 116.543 171.487 259.331 1719 19/4.50 7/8 22.22 159.691 248.211 354.523 2352 19/5.08 1 25.4 209.066 325.61 464.839 2384 37/3.63 1 25.4 205.508 319.827 456.832 3061 37/4.09 11.8 28.58 262 407.457 581.827 4006 37/4.55 11/4 31.75 324.72 505.318 721.502 4833
Production Equipment
Test Equipment
Our Services
1. Sufficient support for our tendering representatives.
2. Qualification documents support
3. OEM service available based on official & legal authorization.
4. Strict quality control system.
5. Faster lead time than our competitors.
6. Excellent quality with reasonable price.
7. Strong technical support (technical data, drawing, etc.)
8. Cable solutions to your particular requirements.
9. Free sample is available with economic express fee.
10. Factory acceptance test assistant
11. Container loading design and handling
FAQ
Why choose us ?
1. Geographical location and convenient transportation, saving transportation costs
2. Full range of products, good reputation.
3. The leading edge technology. Different dedicated engineers and technicians for factory production, domestic sales and foreign sales, service and other jobs.
4. The sophisticated management system and management team. ISO9001,14001 and GB / T28001 passed. Computer management system for sales and production, etc.
5. Advanced service concept and positive attitude.
