• Wire Core Material：Bare Copper Wire
• Certification：ISO, CCC, CE, UL, VDE
• Model：Yjsv
• Transport Package：Wooden or Wooden-Steel Drum
• Specification：4,0AWG 2,0AWG
• Trademark：YIFANG
• Origin：Henan, P. R. China
• HS Code：8544492100
• Production Capacity：1000km,Month

Basic Info.

Wire Core Material Bare Copper Wire Certification ISO, CCC, CE, UL, VDE Model Yjsv Transport Package Wooden or Wooden-Steel Drum Specification 4/0AWG 2/0AWG Trademark YIFANG Origin Henan, P. R. China HS Code 8544492100 Production Capacity 1000km/Month

Product Description

Applications



Medium voltage UD-P suitable for Primary Underground Distribution System; buried directly or installed in underground ducts or conduits or exposed to sunlight for above ground application. To be used at 15,000 volts or less. Rated for continuous operation at 90°C conductor temperature.







Description



Conductor:                      Bare aluminum or copper stranded class B conductor (compressed stranding).



Strand Shield:                Extruded semi-conducting strand shield.



Insulation:                       Cross-linked polyethylene (XLPE) or tree-retardant



                                          cross-linked polyethylene (XLPE-TR) insulation.



Insulation Shield:          Extruded semi-conducting insulation shield.



Neutral Wires:                Coated or uncoated copper concentric neutral wires.



Embedded Jacket:        Non-conducting linear low density PE(LLDPE) encapsulating jacket with exturded red stripes.



                                          Optional semi-conducting PE jacket.







Maximum Conductor Temperature



Normal Continuous    90°C



Overload                     130°C



Short Circuit                250°C







Features



•Simultaneous extrusion of strand shield, insulation and insulation shield (triple extrusion, dry curing process) combines to form a virtually perfect cable core eliminating unequal electrical stress.



•XLPE insulation offers low moisture absorption, good chemical resistance, low dielectric loss and high dielectric strength. XLPE-TR offers, in addition, tree-retardant characteristics.







Options



•Cable in Duct (C-I-C)



•Parallel



•Triplex



•Strand Filled







Specifications



ICEA S-94-649



AEIC CS-8
