Chromel alumel wire 1.0mm class 1 used for thermocouple sensor
Shanghai Tankii Alloy Material Co., Ltd.- Type：Bare
- Conductor Type：Solid
- Application：Heating
- Conductor Material：Chromel Alumel
- Sheath Material：bare
- Insulation Material：Bare
Base Info
- Model NO.：K
- Material Shape：Round Wire
- Range of Application：Temperature Measurement
- Certification：ISO9001, RoHS
- Brand：Tankii
- Item：Chromel alumel wire 1.0mm class 1 used for thermoc
- Round Wire：Chromel Alumel
- Dia：0.3,0.5,0.8,1.0,1.2,1.6,2.0,2.5,3.2mmm
- Surface：Bright, oxidized
- Grade：I,II,III
- Transport Package：18kg,Spool
- Specification：0.1mm to 8mm
- Trademark：TANKII
- Origin：Shanghai
- HS Code：75052200
- Production Capacity：10 Ton,Month for 0.5mm 0.8mm 1.2mm Thermocouple Wi
Description
Chemical Composition
Conductor Name
Polarity
Code
Nominal Chemical Composition /%
Ni
Cr
Si
Ni-Cr
Positive
KP
90
10
--
Ni- Si
Negative
KN
97
--
3
Diameter/mm
Long time Working temperature /ºC
Short period Working temperature /ºC
0.3
700
800
0.5
800
900
0.8,1.0
900
1000
1.2,1.6
1000
1100
2.0,2.5
1100
1200
3.2
1200
1300
Packing & Delivery
Packaging Details: 500m/1000m per roll with plastic film wrapped and carton package. As the order quantity and customer requirement.
Delivery Detail: About 7 days, as the order quantity.
