Liycy Tp PVC Insulation 0.14*2*2c Screened Paired Flexible Data Transmission Cable with Color Code Twisted Data Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Solid
- Application：Overhead, Underground
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：LIYCY TP
- Material Shape：Round Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, UL, CCC, RoHS, VDE
- Brand：Feiya
- Color：Black Red Yellow, According to Voltage Level
- Whether It Is Environmentally Friendly：Yes
- Whether Quality Inspection：Provide Inspection Certificate
- Standard：Customized According to Specified National Standar
- OEM/ODM：Accepted
- Core：Single Core and Multicore
- Transport Package：Standard Export Packaging
- Specification：International General Specifications
- Trademark：Fengda
- Origin：Tianjin, China(Mainland)
- HS Code：8544492100
- Production Capacity：100000,Day
Description
Application
LiYCY TP cable is a paired and screened PVC data cable with small outer diameter. This cable is applied in measuring, control, and voice signals, e.g. in low-voltage switchboard plants, scales and appliance engineering, in communication technologies, in control and measuring technologies, and in office and computing machines.
Outstanding features
- screened, good EMV characteristic
- flexible
- small outer diameter
- small bending radius
Construction
| Conductor | bare copper strands with reference to VDE 0812 |
|---|---|
| Insulation | PVC, TI2 acc. to EN 50363-3 + VDE 0207-363-3 |
| Colour code | with reference to DIN 47100 |
| Stranding | cores twisted to pairs, pairs in layers |
| Wrapping | PETP foil |
| Screen | tinned copper braiding with a tinned copper drain wire (0,34 mm²) |
| Sheath material | PVC, TM2 acc. to EN 50363-4-1 + VDE 0207-363-4-1 |
| Sheath colour | grey (RAL 7032) |
Technical data
| Peak operating voltage | < 0,25 mm² = max. 350 V ≥ 0,25 mm² = max. 500 V |
|---|---|
| Testing voltage | core/core 1500 V core/screen 1200 V |
| Min. bending radius | fixed laying: 5 x d flexible application: 10 x d |
| Radiation resistance | 8 x 10^7 cJ/kg |
| Temperature range | fixed laying: -30/+70 °C flexible application: -5/+70 °C |
| Fire performance | flame retardant and self-extinguishing acc. to IEC 60332-1-2 + VDE 0482-332-1-2 |
