• Model NO.：NYCY cable BM60
• Wire Core Material：Red Copper Wire
• Certification：ISO, CCC, CE
• Model：YJV
• Brand：Yifang
• Size：up to 800mm2
• Alternative Voltage：up to 35kv
• Armour：Swa or Sta
• Transport Package：Wooden Drum
• Specification：CE
• Trademark：yifang
• Origin：Zhengzhou, China
• HS Code：8544601200
• Production Capacity：300km,Month

Conductor:According to VDE 0295 and IEC 60228, class 1 single wire conductorsCore insulation:PVC and colour coded to VDE 0293, more than 6 cores number codedBedding:PVCConcentric Conductor:Stranded concentrically Concentric conductors in inner layer of round copper wires, outer layer with copper tapeOuter Sheath:PVC BlackVoltage Rating:0.6 - 1kVTemperature Range:Flexing:- 5°C to + 50°C Static:-30°C to + 70°CBending Radius:Single conductor 15 x Ø
Multi conductor 12 x Ø

Core Marking

NYY-J:With protective earth

Cable Ordering

Number of cores and cross section mm²Copper weight kg/kmApproximate outside in mm ca.Approximate weight kg/100m2 x 1.5 RE /1.552.013.02453 G 1.5 RE/1.566.014.02904 G 1.5 RE/1.581.015.03307 G 1.5 RE/2.5133.017.044010 G 1.5 RE/2.5176.019.055012 G 1.5 RE/2.5205.020.062014 G 1.5 RE/2.5235.021.068019 G 1.5 RE/4320.023.084024 G 1.5 RE/6415.026.01,03030 G 1.5 RE/6500.027.01,18040 G 1.5 RE/10696.030.01,5002 x 2.5 RE/2.580.014.03103 G 2.5 RE/2.5105.015.03504 G 2.5 RE/2.5128.016.04107 G 2.5 RE/2.5200.018.054010 G 2.5 RE/4286.021.073012 G 2.5 RE/4334.022.080014 G 2.5 RE/6403.023.090019 G 2.5 RE6523.025.01,09024 G 2.5 RE/10696.028.01,37030 G 2.5 RE/10840.030.01,58040 G 2.5 RE/101,080.033.01,9703 G 4 RE/4161.016.04804 G 4 RE / 4200.018.05503 G 6 RE / 6240.018.05904 G 6 RE / 6297.019.0690

NYCWY Cable *

   2 G 10 RE/10312.019.06803 G 10 RE/10408.020.07804 G 10 RE/10504.021.09103 G 16 RE/16643.022.01,1004 G 16 RE/16796.024.01,2503 G 25 RM/251,003.027.01,6504 G 25 RM/161,142.029.01,8503 G 35 SM/161,190.026.01,1703 G 35 SM/351,402.027.01,9904 G 35 SM/161,526.029.02,1503 G 50 SM/251,723.030.02,3003 G 50 SM/502,000.031.02,5004 G 50 SM/252,203.034.02,9503 G 70 SM/352,410.034.03,1503 G 70 SM/702,796.034.03,5004 G 70 SM/353,082.038.03,9503 G 95 SM/503,296.039.04,2003 G 95 SM/95 3,791.039.04,7004 G 95 SM/504,208.043.05,3004 G 120 SM/705,388.047.06,6504 G 150 SM/706,540.051.07,9504 G 185 SM/958,159.057.09,900
