15kv Primary Ud Cable Trxlp Insulation
YIFANG ELECTRIC GROUP INC.- Application：Underground
- Voltage：Low and Medium Voltage Cable
- Current：DC & AC
- Insulation Material：XLPE
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：15kV UD cable BM19
- Wire Core Material：Bare Copper Wire
- Certification：ISO, CCC, CE, RoHS, UL, VDE
- Model：YJV
- Brand：Yifang
- Conductor Option：Copper or Aluminum
- Transport Package：Wooden or Wooden-Steel Drum
- Specification：15kv UD cable
- Trademark：Yifang Cable
- Origin：Zhengzhou, China
- HS Code：8544601200
- Production Capacity：300km,Month
Description
Phase Conductor
Neutral
Thickness Per Cond. (mils)
Diameter (mils)
Weight
1000 feet
(lbs.)
Allowable
Ampacities+
Size (AWG or kcmil)
Strand- ing
No. of
Wires
Size
(AWG)
Nominal
Insul.
Insul. Shield min. Point
Approx. Jkt.
Bare Phase Cond.
Over
Insul.
Over Insul. Shield
Comp. Cable
Comp. Cable
Direct
Burial
In
Ducts
ALUMINUM CONDUCTOR - 100% INSULATION LEVEL
2
Solid
10
14
175
30
50
258
653
733
961
453
168*
119*
2
7
10
14
175
30
50
283
678
758
986
470
168*
119*
1
Solid
13
14
175
30
50
289
685
765
993
520
193*
137*
1
19
13
14
175
30
50
322
718
798
1026
539
193*
137*
1/0
Solid
16
14
175
30
50
325
720
800
1028
591
218*
155*
1/0
19
16
14
175
30
50
352
748
828
1056
609
218*
155*
2/0
19
20
14
175
30
50
395
790
870
1098
703
248*
177*
3/0
19
25
14
175
30
50
443
838
918
1146
817
284*
201*
4/0
19
20
12
175
30
50
498
893
973
1234
993
324*
230*
250
37
16
10
175
30
50
558
963
1043
1346
1213
360*
257*
350
37
18
14
175
40
50
661
1068
1168
1396
1055
389**
319**
500
37
25
14
175
40
50
789
1193
1293
1521
1349
468**
384**
750
61
24
12
175
40
80
968
1383
1483
1798
1946
569**
468**
1000
61
20
10
175
40
80
1117
1530
1630
1988
2473
642**
542**
1250
91
25
10
220
55
80
1250
1765
1895
2253
3142
688**
604**
1500
91
30
10
220
55
80
1370
1885
2015
2373
3616
726**
637**
COPPER CONDUCTOR - 100% INSULATION LEVEL
2
Solid
16
14
175
30
50
258
653
733
961
664
210*
150*
2
7
16
14
175
30
50
283
678
758
986
684
210*
150*
1
Solid
20
14
175
30
50
289
685
765
993
780
240*
171*
1
19
20
14
175
30
50
322
718
798
1026
803
240*
171*
1/0
Solid
25
14
175
30
50
325
720
800
1028
922
273*
194*
1/0
19
25
14
175
30
50
362
758
838
1066
951
273*
194*
2/0
19
20
12
175
30
50
405
800
880
1142
1161
313*
224*
3/0
19
25
12
175
30
50
456
853
933
1194
1390
358*
255*
4/0
19
20
10
175
30
50
512
908
988
1291
1717
410*
293*
250
37
24
10
175
30
50
558
963
1043
1346
1992
446*
322*
350
37
18
12
175
40
50
661
1068
1168
1429
1964
489**
400**
500
37
26
12
175
40
50
789
1193
1293
1554
2651
577**
472**
750
61
25
10
175
40
80
968
1383
1483
1840
3906
649**
532**
1000
61
26
9
175
40
80
1117
1530
1630
2013
5041
720**
630**
1250
91
26
8
175
55
80
1250
1765
1895
2306
6400
760**
667**
+ Ampacities shown assume use of 100% load factor, 60 Hz current, 36" burial depth, 20°C ambient temperature, 90°C
conductor temperature, earth RHO 90, insulation and shield RHO 400
* Full neutral construction (Ampacities assume - single phase circuit, one cable)
** 1/3 neutral cable (Ampacities assume - three phase circuit, 3 cables triplexed, multi-point grounding per ICEA methods)
