H01n2-D/E Polychloroprene Cables Insulation Copper Conductor Electric Wire Welding Electrode Cables
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Underground
- Conductor Material：Copper
- Sheath Material：Rubber
- Insulation Material：Rubber
Base Info
- Model NO.：H01n2-D,E, 60245 IEC 81
- Material Shape：Round Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, UL, CCC, RoHS, VDE
- Brand：Feiya
- Color：Black Red Yellow, According to Voltage Level
- Whether It Is Environmentally Friendly：Yes
- Whether Quality Inspection：Provide Inspection Certificate
- Standard：Customized According to Specified National Standar
- OEM/ODM：Accepted
- Core：Single Core and Multicore
- Transport Package：Standard Export Packaging
- Specification：International General Specifications
- Trademark：Fengda
- Origin：Tianjin, China(Mainland)
- HS Code：8544492100
- Production Capacity：100000,Day
Description
Class 6 Extra Flexible Copper
PET (Polyester Tape)
Rubber
Rated voltage Uo/U : 100/100 V.
Test voltage : 1 kV.
Max. temperature at conductor : 85° C.
Max. operating temperature, fixed : -20 ~ +85° C.
Protective conductor : no.
Flame retardant : yes.
H01N2-D : cable with normal flexibility.
H01N2-E : cable with high flexibility.
H01N2-D/-E arc welding rubber cable - Standards
Cable : EN 50525-2-81.
Core identification : VDE 0293 (HD308); more than 5 cores: gn-ye + numbers.
Flame retardant : VDE 0482-332-1-2/IEC 60332-1.
Oil resistant : EN 660811-2-1.
