• Model NO.：1x50 NFC 33 226
• Wire Core Material：Bare Copper Wire
• Certification：ISO, CCC, CE, RoHS, UL, VDE
• Model：3X150 NFC 33 226 18,30,36kv
• Brand：Yifang Cable
• Rated Voltage：18,30kv
• Conductor：Copper
• Insulation Screen：with Powder Over It
• Sheath：PE
• Sheath Color：Black
• Cores：Single Bundle
• Section Area：50mm2
• Country Exported：West Africa:Togo,Cote Diva,etc
• Other Sizes：3X240mm2,3X150
• Other Voltage：18,30kv
• Transport Package：Wooden Drum or Wooden Steel Drum
• Specification：1.1m drum or 2.2drum
• Trademark：Yifang Cable
• Origin：China
• HS Code：8544601200
• Production Capacity：1000km Per Month

DESCRIPTIONUtilisationLe câble MT NFC 33-226 est destiné à la distribution publique moyenne tension HTA 12/20 kV.Il peut être constitué de 1 ou 3 conducteurs de phase.L'étanchéité longitudinale est assurée par une poudre gonflante.La technologie de sa fabrication permet de le poser sans protection mécanique
supplémentaire. Norme : NF C 33 226, IEC 60502-2



TECHNICAL DATA SHEETCâble HN33S26-18/30kV 1x50mm² Alu NF C 33 S226No.DescriptionUnitSpecification1Reference standard/NFC 33-226,IEC 60502-22Rated voltageKV18/303Number of individual cores/14Nominal conductor areamm²505Material of conductor/Compacted circular aluminumNumber of strands/Min.6Diameter of conductormm7.7~8.6Max.conductor D.C resistance at 20ºCOhm/km0.6416Material of conductor screen/Semi-conducting compoundNominal thickness of conductor screenmm0.77Material of insulation/XLPENominal thickness of insulationmm8.08Material of insulation screen/Semi-conducting compound,longitude with grooves, and sealing powder over itNominal thickness of insulation screenmm0.89Metallic screen layer/Longitude aluminum plastic tapeThickness of aluminum tapemmMin. 0.210Outer sheath material/Black PENominal thicknessmm2.011Approx. overall diameter of the cablemm32.512Approx. weight of the cableKg/km930
