FTP CAT6 Outdoor/Indoor LAN Cable Communication Cable

GENERAL CLAD CO., LTD.
  • Application：Local Communication Cable, Coaxial Cable, LAN Cable, RF Cable
  • Conductor Material：Copper
  • Cover Material：PVC
  • Type：Cat 6
  • Material Shape：Round Wire
  • Conductor Type：Solid

Base Info

  • Model NO.：FTP CAT6
  • Wire Core Material：Bare Copper Wire
  • Certification：CE, ISO, RoHS
  • Color：Grey, Blue, Black, Yellow, Red etc
  • Transport Package：Carton Box
  • Specification：305m,roll
  • Trademark：General Clad
  • Origin：China
  • Production Capacity：10000 Boxes, Month

Description


FTP CAT6 Outdoor/Indoor LAN Cable Communication Cable
FTP CAT6 Outdoor/Indoor LAN Cable Communication Cable
FTP CAT6 Outdoor/Indoor LAN Cable Communication Cable
FTP CAT6 Outdoor/Indoor LAN Cable Communication CableDescriptionRated temperature -20--75ºC
Standard UL444, TIA/EIA568B, ISO/IEC11801
23 awg wire gauge
A single bare copper conductor
Insulating high density polyethylene
Line of 4
Sheathed polyvinyl chloride
Tear the rope as neededElectrical properties1.0~ 500.0mhz characteristic impedance (ohms) 100±15
1.0~ 500.0mhz delay difference (ns/100m) ≤45
At 20ºC, the maximum dc resistance (ohms/km) of the conductor is less than or equal to 65.8
Conductor resistance unbalance (%) ≤1.0Application100 Base - T4
100 Base - TX
100 VG - AnyLAN
155 Mbps ATM
622 Mbps ATM

   Package

FTP CAT6 Outdoor/Indoor LAN Cable Communication Cable
FTP CAT6 Outdoor/Indoor LAN Cable Communication Cable
FTP CAT6 Outdoor/Indoor LAN Cable Communication Cable
