• Material Shape：Round Wire
• Certification：ISO9001, CE, UL, CCC
• Brand：Yifang
• Transport Package：Wooden Drum
• Origin：China
• Production Capacity：500km,Month

Code name

Nominal aluminium area

Stranding and wire     diameter

Sectional area of aluminium

Total sectional area

Approx. overall diameter

Approx. mass

Calculated D.C. resistance at 20^oC

Calculated breaking load

Al

Steel

mm²

No./mm

mm²

mm²

mm

kg/km

Ω/km

kN

RABBIT

50

6/3.35

1/3.35

52.88

61.7

10.05

214

0.5426

18.35

DOG

100

6/4.72

7/1.57

105

118.5

14.15

394

0.2733

32.7

WOLF

150

30/2.59

7/2.59

158.1

194.9

18.13

726

0.1828

69.2

DINGO

150

18/3.35

1/3.35

158.7

167.5

16.75

506

0.1815

35.7

LYNX

175

30/2.79

7/2.79

183.4

226.2

19.53

842

0.1576

79.8

ZEBRA

400

54/3.18

7/3.18

428.9

484.5

28.62

1621

0.0674

131.9

AAC Technical Characteristics Based on Standard DIN 48201 / DIN EN50182

Code number

Area

Number of wires

Wire     diameter

Conductor diameter

Linear mass

Rated strength

D.C. resistance at 20^oC

mm²

No.

mm

mm

kg/km

kN

Ω/km

16

15.9

7

1.7

5.1

43.4

3.02

1.7986

25

24.2

7

2.1

6.3

66.3

4.36

1.1787

35

34.4

7

2.5

7.5

93.9

6.01

0.8317

50

49.5

7

3

9

135.2

8.41

0.5776

50

48.3

19

1.8

9

132.9

8.94

0.5944

70

65.8

19

2.1

10.5

180.9

11.85

0.4367

95

93.3

19

2.5

12.5

256.3

16.32

0.3081

120

117

19

2.8

14

321.5

19.89

0.2456

150

147.1

37

2.25

15.8

405.7

26.48

0.196

185

181.6

37

2.5

17.5

500.9

31.78

0.1588

240

242.5

61

2.25

20.3

671.1

43.66

0.1193

300

299.4

61

2.5

22.5

828.5

52.4

0.0966

AAAC Technical Characteristics Based on Standard BS 3242

Code name

Nominal aluminium area

Stranding and wire     diameter

Sectional area

Approx. overall diameter

Approx. mass

Calculated D.C. resistance at 20^oC

Calculated breaking load

mm²

No./mm

mm²

mm

kg/km

Ω/km

kN

ALMOND

25

7/2.34

30.1

7.02

82

1.094

8.44

CEDAR

30

7/2.54

35.47

7.62

97

0.9281

9.94

FIR

40

7/2.95

47.84

8.85

131

0.688

13.4

HAZEL

50

7/3.30

59.87

9.9

164

0.5498

16.8

OAK

100

7/4.65

118.9

13.95

325

0.2769

33.3

ASH

150

19/3.48

180.7

17.4

497

0.183

50.65

ELM

175

19/3.76

211

18.8

580

0.1568

59.1

UPAS

300

37/3.53

362.1

24.71

997

0.09155

101.5

About us

Zhengzhou Yifang Cable Co., Ltd is a large joint-stock, hi-tech enterprise established in 2001. We are specialized in wires & cables, including designment, production and sales. Located in Zhengzhou, China, our factory's position is extremely advantageous.

There are more than 500 staffs in our factory including over 50 technical personnel, 5 senior engineers. With complete advanced cable producing equipments over 150 sets, complete testing equipments, a national level fire-resistant & flame retardant cable laboratory. Our technology has reached advanced levels at home and abroad.

Our main products include: Power Cable for voltage up to 220KV, Overhead insulated cable, ABC Cable, Building Cable and flexible cord, Control Cable, Rubber Cable, Bare Conductor(ACSR, AAC, AAAC, BCC), Welding Cable, Galvanized Steel Wire(Stay wire),flame retardant mining cable, etc

We have own IM/EX right, our products have been exported to Europe, Australian, Middle-east, South-east Asia, Africa, American, South American etc., being subjected to consistent good opinion of customers.
