High Quality Quadruplex Service Drop / ABC Cable
Henan Jiapu Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead
- Conductor Material：Aluminum
- Sheath Material：PVC
- Insulation Material：XLPE
Base Info
- Model NO.：JKLYJ
- Certification：ISO9001, CE, SABS
- Brand：Henan Jiapu
- Conductor：Aluminum
- Jacket：None
- Armor：None
- Voltage Rating：0.6,1kv,10kv
- No.of Cores：1-4 Cores
- Applicable Standard：ASTM, BS, CSA, DIN
- Transport Package：Wooden Drum or Wooden&Steel Drum
- Specification：IEC ASTM BS DIN, Any standard
- Trademark：jiapu
- Origin：Henan China
- HS Code：4101962331
- Production Capacity：5000km,Month
Description
Code Name
Phase Conductor
Bare Neutral
Approx.Weight
Code Name
Phase Conductor
Bare Neutral
Approx. Weight
Size
Stranding
Insulation Thickness
Size
Stranding
XLPE
PE
Size
Stranding
Insulation Thickness
Size
Stranding
XLPE
PE
AWG
-
mil
AWG
-
lbs/1000ft
AWG
-
mil
AWG
-
lbs/1000ft
6201 Alloy Neutral Messenger
AAC Neutral Messenger
Bay
6
Solid
45
6
7
145
140.0
Clydesdale
4
Solid
45
4
7
208
201.8
French Coach
6
7/w
45
6
7
155
144.3
Pinto
4
7/w
45
4
7
223
207.9
German Coach
4
Solid
45
4
7
214
208.3
Mustang
2
7/w
45
2
7
333
312.6
Arabian
4
7/w
45
4
7
229
214.4
Criollo
1/0
19/w
60
1/0
7
529
504.5
Belgian
2
7/w
45
2
7
344
323.1
Percheron
2/0
19/w
60
2/0
7
649
620.5
Shetland
1/0
19/w
60
1/0
7
546
521.1
Hanoverian
3/0
19/w
60
3/0
19
799
765.6
Thoroughbred
2/0
19/w
60
2/0
7
670
641.5
Oldenburg
4/0
19/w
60
4/0
19
986
946.7
Trotter
3/0
19/w
60
3/0
7
825
791.8
Lippizaner
336.4
19/w
60
336.4
19
1,546
1,519.2
Walking
4/0
19/w
60
4/0
7
1019
979.7
ACSR Neutral Messenger
Morochuca
6
Solid
45
6
6/1
152
147.4
Grullo
2/0
19/w
60
2/0
6/1
707
678.7
Chola
6
7/w
45
6
6/1
162
151.7
Suffolk
3/0
19/w
60
3/0
6/1
872
838.9
Morgan
4
Solid
45
4
6/1
226
220
Appaloosa
4/0
19/w
60
4/0
6/1
1079
1039.2
Hackney
4
7/w
45
4
6/1
241
226.1
Bronco
336.4
19/w
60
336.4
18/1
1613
1568.2
Palomino
2
7/w
45
2
6/1
362
342.6
Gelding
336.4
19/w
60
4/0
6/1
1548
1494.3
Costena
1/0
19/w
60
1/0
6/1
575
550.6
Note:
(1)Designated sizes are: ACSR 6/1 diameter equivalent and AAC with equivalent resistivity per ASTM B-399 for 6201.
(2)Conductor temperature of 90°C for XLP, 75°C for poly; ambient temperatures of 40°C; emissivity 0.9; 2ft./sec/wind in sun.
