PVC Electric Wire Tri-Rated BS H05V-K 1.5mm2 H07V2-K Flexible Cu PVC Insulation Black White Red Pink Elevator Cable Aluminium Copper Control Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Application：Construction, Overhead, Underground, Industrial, Power Station, Telecommunication, Computer, Car, Installation in Ground, Indoors, Outdoors.
- Voltage：Low and Medium Voltage Cable
- Current：DC & AC
- Insulation Material：PVC (Polyvinyl Chloride)
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：Tri-rated H05V2-K , H07V2-K
- Wire Core Material：Class 5 Flexible Copper Conductor
- Certification：ISO, CCC, CE, RoHS, UL, VDE
- Model：Tri-Rated H05V2-K , H07V2-K
- Brand：Feiya
- OEM&ODM：Yes
- Rated Voltage：H05V2-K: 300,500 H07V2-K: 450,750V
- Operating Environment：Use in The Switch Control
- Other Service：Can Be Customized
- Colors：Can Be Customized
- Inner Sheath：Rubber Type GM1b.
- Transport Package：Wooden Box Packing or Pallet Shipping Containers
- Specification：PVC copper
- Trademark：Feiya
- Origin：China
- HS Code：8544
- Production Capacity：80000 Meter,Meters Per Month
Description
APPLICATION
Heat resistant, flame retardant cable designed for use in the switch control, relay and instrumentation panels of power switchgear and for purposes such as internal connectors in rectifier equipment, motor starters and controllers. Tri-rated cable is sometimes referred to as BS 6231 cable, H07V2-K or panel wire.
CHARACTERISTICS
Voltage Rating
(Uo/U) UL, CSA, BS 6231: 0.6/1kV
0.5mm² - 1mm²: BS EN 50525-2-31 - H05V2-K: 300/500V
1.5mm² and above*: BS EN 505-2-31 - H07V2-K: 450/750V
Temperature Rating
UL, CSA: -15°C to +105°C
BS 6231: -15°C to +90°C
Minimum Bending Radius 6 x overall diameter
CONSTRUCTION
UL Style Number 1015
Conductor Class 5 flexible copper conductor
Insulation PVC (Polyvinyl Chloride)
