1/2 Core FTTH Cable LSZH Jacket Self-Supporting Outdoor Optic Fiber Cable
DONGGUAN TW-SCIE CO., LTD.- Application：Communication, Drop Cable
- Type：Single-mode Fiber
- Connection Structure：Drop Cable
- Allowed Lateral Pressure：100(N,100mm)<1000(N,100mm)
- Allowed Tensile Strength：<100N
- Core：Single Core
Base Info
- Model NO.：FTTH cable
- Certification：RoHS, UL, CE, ISO9001, Drop Cable
- Sheath Material：LSZH FTTH Cable
- Product Name：Drop Cable
- Messenger Material：Steel Wire
- Other Messenger Material：FRP, Kfrp
- Jacket Material：Lszh
- Jacket Color：Black, White
- Installation Style：Indoor & Outdoor Aerial Drop Cable
- Optical Fiber Type：G.657A
- Fiber Color：Blue, Orange, Green, Brown
- Outer Diameter of Cable：2.0mm*5.0mm
- Diameter of Messenger Wire：1.0mm
- Transport Package：Wooden Drum
- Specification：SGS ROHS REACH ISO
- Trademark：TW-SCIE drop cable or OEM
- Origin：China (Mainland) Guangdong Dongguan
- HS Code：8544700000
- Production Capacity：200km,Day
Description
Dong Guan TW-SCIE Co., Ltd. is a high-tech enterprise group in China devoted to communications undertakings with our own importers and exporters rights. Since its founding, high quality products an strong co-operations have enabled the enterprise to stably and rapidly grow into a specialized communication manufacturer supplier and engineering service provider the most complete product line-up and specifications in the fiber and cable industry of China.
The enterprise is possessed of a passel of faithful, intelligent, conscientious talents. While bending ourselves to following with the worldwide advanced development and application, we build up cooperation ties with many scientific research academy.
The main products of our enterprise are:
Drop cable, optical cable, drop cable, Optical media converter, optical transceiver, optical coupler, optical modem, optical connector, optical distribution frame.
All of the products are widely used in telecom, electric power, railway and other related department, exporting France, India, Singapore, Malaysia.
| ITEMS | UNITS | SPECIFICATION |
| Attenuation | dB/km | ≤0.4 at 1310nm ≤0.3 at 1550nm |
| Chromatic Dispersion | ps/nm.km | ≤3.5 at 1285nm ~ 1330nm ≤18.0 at 1550nm |
| Zero Dispersion Wavelength | nm | 1300 ~ 1324 |
| Zero Dispersion Slope | ps/nm2.km | ≤0.095 |
| Cut-off Wavelength (λcc, 22m of a cabled fiber) | nm | ≤1260 |
| Mode Field Diameter | um | 9.2±0.5 |
| Mode Field Concentricity | um | ≤0.8 |
| Cladding Diameter | um | 125±1.0 |
| Cladding Non-circularity | % | ≤1.0 |
| Coating cladding concentricity error | um | ≤12.5 |
| Coating Diameter | um | 245±10 |
| Bending loss (Bare fiber) Radius :7.5mm x 1 turn | dB | ≤0.5 at 1550nm |
| Proof Test | kpsi | ≥100 |
If any questions, please feel free to contact us. Looking forward to serving with you.
